Sony HCD-DX80 - Page 71

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
71
HCD-DX80
R696 1-249-417-11 CARBON 1K 5% 1/4W
R697 1-249-417-11 CARBON 1K 5% 1/4W
R698 1-249-417-11 CARBON 1K 5% 1/4W
R699 1-249-417-11 CARBON 1K 5% 1/4W
R721 1-249-429-11 CARBON 10K 5% 1/4W
R722 1-249-430-11 CARBON 12K 5% 1/4W
R734 1-247-807-31 CARBON 100 5% 1/4W
R735 1-247-885-00 CARBON 180K 5% 1/4W
R736 1-249-429-11 CARBON 10K 5% 1/4W
R737 1-249-433-11 CARBON 22K 5% 1/4W
R738 1-249-417-11 CARBON 1K 5% 1/4W
R739 1-249-441-11 CARBON 100K 5% 1/4W
R742 1-249-417-11 CARBON 1K 5% 1/4W
R743 1-249-429-11 CARBON 10K 5% 1/4W
R744 1-249-441-11 CARBON 100K 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
R746 1-249-417-11 CARBON 1K 5% 1/4W
R748 1-249-441-11 CARBON 100K 5% 1/4W
R802 1-249-441-11 CARBON 100K 5% 1/4W
R803 1-249-441-11 CARBON 100K 5% 1/4W
R804 1-249-441-11 CARBON 100K 5% 1/4W
R805 1-249-441-11 CARBON 100K 5% 1/4W
R806 1-249-441-11 CARBON 100K 5% 1/4W
R807 1-249-441-11 CARBON 100K 5% 1/4W
R808 1-249-441-11 CARBON 100K 5% 1/4W
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-249-441-11 CARBON 100K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV722 1-227-360-11 RES, VAR, CARBON 50K (MIC LEVEL)
< SWITCH >
S601 1-771-410-21 SWITCH, TACTILE (MD (VIDEO))
S602 1-771-410-21 SWITCH, TACTILE (TAPE A/B)
S603 1-771-410-21 SWITCH, TACTILE (CD)
S604 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S605 1-771-410-21 SWITCH, TACTILE (GAME)
S606 1-771-410-21 SWITCH, TACTILE
(SURROUND SPEAKER MODE)
< VIBRATOR >
X601 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
**************************************************************
A-4476-270-A POWER AMPLIFIER BOARD, COMPLETE (MX)
A-4476-767-A POWER AMPLIFIER BOARD, COMPLETE
(E2, E51, AR)
A-4476-770-A POWER AMPLIFIER BOARD, COMPLETE (SP)
A-4726-062-A POWER AMPLIFIER BOARD, COMPLETE (BR)
*********************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-162-286-31 CERAMIC 220PF 10% 50V
C503 1-162-281-21 CERAMIC 100PF 10% 50V
C504 1-104-665-11 ELECT 100uF 20% 10V
C507 1-136-495-11 FILM 0.068uF 5% 50V
C508 1-136-495-11 FILM 0.068uF 5% 50V
C509 1-128-560-11 ELECT 22uF 20% 100V
C512 1-162-300-21 CERAMIC 0.01uF 50V
C514 1-162-300-21 CERAMIC 0.01uF 50V
C541 1-136-165-00 FILM 0.1uF 5% 50V
C542 1-137-838-11 ELECT 2200uF 20% 42V
(EXCEPT SP)
C542 1-137-844-11 ELECT 2200uF 20% 42V
(SP)
C544 1-137-749-11 MYLAR 0.1uF 100V
C545 1-137-749-11 MYLAR 0.1uF 100V
C546 1-137-843-11 ELECT 2200uF 20% 100V
(EXCEPT SP)
C546 1-137-849-11 ELECT 2200uF 20% 100V
(SP)
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-162-286-31 CERAMIC 220PF 10% 50V
C553 1-162-281-21 CERAMIC 100PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
C557 1-136-495-11 FILM 0.068uF 5% 50V
C558 1-136-495-11 FILM 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C581 1-126-967-91 ELECT 47uF 20% 50V
C591 1-136-165-00 FILM 0.1uF 5% 50V
C592 1-137-838-11 ELECT 2200uF 20% 42V
(EXCEPT SP)
C592 1-137-844-11 ELECT 2200uF 20% 42V
(SP)
C596 1-137-843-11 ELECT 2200uF 20% 100V
(EXCEPT SP)
C596 1-137-849-11 ELECT 2200uF 20% 100V
(SP)
C942 1-126-964-11 ELECT 10uF 20% 50V
C943 1-126-968-11 ELECT 100uF 20% 50V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D503 8-719-947-70 DIODE MTZJ-T-72-18C
D504 8-719-947-70 DIODE MTZJ-T-72-18C
D541 8-719-500-60 DIODE D5SBA20
D543 8-719-510-68 DIODE D5SBA204101
D551 8-719-911-19 DIODE 1SS133T-72
D581 8-719-911-19 DIODE 1SS133T-72
D941 8-719-150-92 DIODE MTZJ-T-72-33D
< EARTH TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
* EP502 1-537-738-21 TERMINAL, EARTH
PANEL POWER AMPLIFIER
