Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
73
HCD-DX80
< SWITCH >
0 S901 1-786-055-11 SELECTOR, VOLTAGE
(VOLTAGE SELECTOR) (EXCEPT MX)
< TRANSFORMER >
0 T972 1-437-331-21 POWER TRANSFORMER
**************************************************************
1-680-692-11 VIDEO SWITCH BOARD
*******************
< CONNECTOR >
CN607 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< JACK >
J401 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JR781 1-216-864-11 SHORT 0
************************************************************
MISCELLANEOUS
**************
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-757-418-11 WIRE (FLAT TYPE) (21 CORE) (AR)
104 1-757-683-11 CABLE, FLAT (21 CORE) (EXCEPT AR)
0 108 1-757-813-21 CORD, POWER (BR)
0 108 1-777-071-51 CORD, POWER (EXCEPT BR)
509 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
556 1-757-710-11 WIRE (FLAT TYPE) (16 CORE)
HP901 A-2004-771-A BASE (A) ASSY, HEAD
HRP901 A-2004-772-A BASE (B) ASSY, HEAD
M721 A-4672-826-A MOTOR ASSY
M901 X-3378-241-1 MOTOR ASSY (CAPSTAN)
M961 1-763-072-11 FAN, D.C.
PM901 1-454-887-32 SOLENOID, PLUNGER
PM901 1-454-887-32 SOLENOID, PLUNGER
0 T910 1-437-284-11 TRANSFORMER, POWER (BR)
0 T910 1-437-355-11 POWER TRANSFOMER (EXCEPT BR)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-103-19 + PTPWH (2X5)
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#4 7-685-881-09 SCREW +BVTT 4X8 (S)
#5 7-627-853-28 SCREW, PRECISION +P 2X3 TYPE3
#6 7-628-254-05 SCREW +PS 2.6X5
#7 7-623-921-01 RING, RETAINING, CAPSTAN
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-569-008-21 ADAPTOR, CONVERSION 2P (EXCEPT BR)
1-793-184-21 CONNECTOR (F TYPE ADAPTOR) (EXCEPT BR)
SUB TRANS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
