80
HCD-GNZ5D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN401 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN402 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D410 8-719-210-21 DIODE 11EQS04
D451 8-719-991-33 DIODE 1SS133T-77
D471 8-719-510-68 DIODE D5SBA204101
D481 8-719-991-33 DIODE 1SS133T-77
D485 8-719-991-33 DIODE 1SS133T-77
D486 8-719-991-33 DIODE 1SS133T-77
D491 8-719-991-33 DIODE 1SS133T-77
< IC >
IC401 6-705-845-01 IC STK403-090
< TRANSISTOR >
Q401 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q402 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q403 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q416 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q417 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q451 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q481 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q482 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R401 1-247-831-11 CARBON 1K 5% 1/4W
R402 1-247-871-11 CARBON 47K 5% 1/4W
R403 1-247-812-11 CARBON 160 5% 1/4W
R404 1-247-871-11 CARBON 47K 5% 1/4W
0R406 1-208-602-11 METAL 0.22X2 2W
R407 1-247-831-11 CARBON 1K 5% 1/4W
R408 1-249-431-11 CARBON 15K 5% 1/4W
R409 1-247-879-11 CARBON 100K 5% 1/4W
R410 1-260-076-11 CARBON 10 5% 1/2W F
0R411 1-212-881-11 FUSIBLE 100 5% 1/4W F
R412 1-247-887-00 CARBON 220K 5% 1/4W
R413 1-249-421-11 CARBON 2.2K 5% 1/4W
R415 1-249-429-11 CARBON 10K 5% 1/4W
R416 1-249-429-11 CARBON 10K 5% 1/4W
R417 1-249-429-11 CARBON 10K 5% 1/4W
R418 1-247-871-11 CARBON 47K 5% 1/4W
0R419 1-202-972-61 FUSIBLE 1 5% 1/4W F
0R420 1-202-972-61 FUSIBLE 1 5% 1/4W F
R421 1-249-429-11 CARBON 10K 5% 1/4W
R425 1-249-439-11 CARBON 68K 5% 1/4W
R426 1-249-426-11 CARBON 5.6K 5% 1/4W
R427 1-249-421-11 CARBON 2.2K 5% 1/4W
R428 1-247-863-11 CARBON 22K 5% 1/4W
R429 1-249-429-11 CARBON 10K 5% 1/4W
R430 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-247-871-11 CARBON 47K 5% 1/4W
R440 1-247-873-11 CARBON 56K 5% 1/4W
R451 1-247-831-11 CARBON 1K 5% 1/4W
R452 1-247-871-11 CARBON 47K 5% 1/4W
R453 1-247-812-11 CARBON 160 5% 1/4W
R454 1-247-871-11 CARBON 47K 5% 1/4W
0 R456 1-208-602-11 METAL 0.22X2 2W
R457 1-247-831-11 CARBON 1K 5% 1/4W
R458 1-249-431-11 CARBON 15K 5% 1/4W
R459 1-247-879-11 CARBON 100K 5% 1/4W
R460 1-260-076-11 CARBON 10 5% 1/2W F
0 R461 1-212-881-11 FUSIBLE 100 5% 1/4W F
R471 1-247-879-11 CARBON 100K 5% 1/4W
R472 1-247-879-11 CARBON 100K 5% 1/4W
0 R480 1-215-890-11 METAL OXIDE 470 5% 2W F
R485 1-247-871-11 CARBON 47K 5% 1/4W
R486 1-247-871-11 CARBON 47K 5% 1/4W
R487 1-249-429-11 CARBON 10K 5% 1/4W
R488 1-247-871-11 CARBON 47K 5% 1/4W
R489 1-249-429-11 CARBON 10K 5% 1/4W
R490 1-249-429-11 CARBON 10K 5% 1/4W
R941 1-247-831-11 CARBON 1K 5% 1/4W
< RELAY >
RY481 1-515-920-11 RELAY (24V)
< THERMISTOR >
TH401 1-807-796-11 THERMISTOR
< TERMINAL BOARD >
TM401 1-694-677-12 TERMINAL BOARD (4P) (FRONT SPEAKER)
*************************************************************
A-1109-321-A JACK BOARD, COMPLETE
*********************
< CAPACITOR >
C1005 1-115-872-11 ELECT 2.2uF 20% 50V
C1006 1-162-955-11 CERAMIC CHIP 150PF 5% 50V
C1007 1-126-786-11 ELECT 47uF 20% 16V
C1008 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C1009 1-115-872-11 ELECT 2.2uF 20% 50V
C1010 1-115-867-11 ELECT 0.1uF 20% 50V
C1011 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1012 1-126-786-11 ELECT 47uF 20% 16V
C1013 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C1014 1-115-868-11 ELECT 0.22uF 20% 50V
C1016 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C1036 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< DIODE >
D1005 6-501-193-01 DIODE 1SS355WTE-17
D1006 6-501-193-01 DIODE 1SS355WTE-17
< GROUND TERMINAL >
EPT1001 1-537-771-21 TERMINAL BOARD, GROUND
EPT1002 1-537-771-21 TERMINAL BOARD, GROUND
< JUMPER RESISTOR >
FB1003 1-216-295-11 SHORT CHIP 0
FB1004 1-216-295-11 SHORT CHIP 0
FRONT AMP JACK
