HCD-GNZ5D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC1001 8-759-710-97 IC NJM4565M-D
< JACK >
J1002 1-770-226-11 JACK (LARGE TYPE) (MIC)
J1004 1-794-702-11 JACK, HEADPHONE (PHONES)
< JUMPER RESISTOR >
JR1000 1-216-295-11 SHORT CHIP 0
< RESISTOR >
R1006 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1007 1-216-813-11 METAL CHIP 220 5% 1/10W
R1008 1-216-809-11 METAL CHIP 100 5% 1/10W
R1009 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R1010 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1011 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1012 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1013 1-216-809-11 METAL CHIP 100 5% 1/10W
R1014 1-216-851-11 METAL CHIP 330K 5% 1/10W
R1015 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1017 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1019 1-216-864-11 SHORT CHIP 0
R1020 1-216-864-11 SHORT CHIP 0
R1031 1-260-083-11 CARBON 47 5% 1/2W
R1032 1-260-083-11 CARBON 47 5% 1/2W
< VARIABLE RESISTOR >
RV1001 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
*************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
*************************************************************
1-687-134-12 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
*************************************************************
OPTICAL BOARD
**************
< CAPACITOR >
C308 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C309 1-126-923-11 ELECT 220uF 20% 10V
< IC >
IC306 6-600-465-11 IC TOTX147 (DIGITAL OUT OPTICAL)
< JUMPER RESISTOR >
R304 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1141-196-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C102 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C103 1-126-916-11 ELECT 1000uF 20% 6.3V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-119-941-11 ELECT 470uF 20% 6.3V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C111 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C113 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C114 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C115 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C116 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C117 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C118 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C119 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C120 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C121 1-119-941-11 ELECT 470uF 20% 6.3V
C122 1-119-941-11 ELECT 470uF 20% 6.3V
C125 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C126 1-119-943-11 ELECT 47uF 20% 50V
C127 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C128 1-126-382-11 ELECT 100uF 20% 16V
C129 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C130 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C144 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C145 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C146 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C147 1-126-382-11 ELECT 100uF 20% 16V
C152 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C153 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C154 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN001 1-568-450-11 HOUSING, CONNECTOR (PC BOARD) 4P
* CN002 1-568-451-11 HOUSING, CONNECTOR (PC BOARD) 10P
CN003 1-784-749-11 CONNECTOR, FFC 27P
CN004 1-784-735-11 CONNECTOR, FFC 13P
CN005 1-779-550-21 CONNECTOR, FFC (LIF(NON-ZIF)) 13P
CN102 1-784-735-11 CONNECTOR, FFC 13P
CN151 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P
CN153 1-818-282-11 PIN, CONNECTOR (FOR PWB) 3P
< DIODE >
D101 6-500-335-01 DIODE MC2838-T112-1
D102 6-500-335-01 DIODE MC2838-T112-1
D105 6-501-193-01 DIODE 1SS355WTE-17
D106 6-501-193-01 DIODE 1SS355WTE-17
D107 6-501-193-01 DIODE 1SS355WTE-17
D108 1-216-295-11 SHORT CHIP 0
D109 6-501-193-01 DIODE 1SS355WTE-17
D110 8-719-053-43 LED SLR-325VCT31 (?/1)
D111 6-501-193-01 DIODE 1SS355WTE-17
D112 6-501-193-01 DIODE 1SS355WTE-17
