84
HCD-GNZ5D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R187 1-216-809-11 METAL CHIP 100 5% 1/10W
R188 1-216-809-11 METAL CHIP 100 5% 1/10W
R189 1-216-809-11 METAL CHIP 100 5% 1/10W
R192 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R193 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R194 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R195 1-216-809-11 METAL CHIP 100 5% 1/10W
R197 1-216-809-11 METAL CHIP 100 5% 1/10W
R198 1-216-864-11 SHORT CHIP 0
R199 1-216-821-11 METAL CHIP 1K 5% 1/10W
R200 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S11 1-762-875-21 SWITCH, KEYBOARD (?/1)
S12 1-762-875-21 SWITCH, KEYBOARD (EQ BAND/MEMORY)
S14 1-762-875-21 SWITCH, KEYBOARD (PRESET EQ)
S15 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S16 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S17 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S18 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S19 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S20 1-762-875-21 SWITCH, KEYBOARD (Z OPEN/CLOSE)
S31 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S32 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S33 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S34 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S35 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S38 1-762-875-21 SWITCH, KEYBOARD ( m TUNING –)
S51 1-762-875-21 SWITCH, KEYBOARD (Y)
S52 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD)
S53 1-762-875-21 SWITCH, KEYBOARD (X)
S54 1-762-875-21 SWITCH, KEYBOARD (x)
S55 1-762-875-21 SWITCH, KEYBOARD (M y TUNING +)
S56 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S57 1-762-875-21 SWITCH, KEYBOARD (DVD)
< VIBRATOR >
X101 1-795-482-11 VIBRATOR, CERAMIC (16MHz)
X102 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
1-687-132-12 SENSOR BOARD
**************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC731 6-600-022-01 IC RPI-576
*************************************************************
SIRCS BOARD
************
< CAPACITOR >
C148 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN143 1-816-423-11 SOCKET, CONNECTOR 3P
< IC >
IC104 6-600-309-01 IC RPM7240-H9 (IR)
< JUMPER RESISTOR >
JR102 1-216-864-11 SHORT CHIP 0
*************************************************************
STREAM BOARD
**************
< DIODE >
D117 8-719-085-33 LED SLI-343URCT32WST
(RING ILLUMINATION)
D118 8-719-085-33 LED SLI-343URCT32WST
(RING ILLUMINATION)
< JUMPER RESISTOR >
JR113 1-216-864-11 SHORT CHIP 0
JR114 1-216-864-11 SHORT CHIP 0
JR115 1-216-864-11 SHORT CHIP 0
JR116 1-216-864-11 SHORT CHIP 0
JR117 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R069 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S101 1-786-289-11 SWITCH, DETECTION (l – EQ + L)
< ROTARY ENCODER >
S102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
*************************************************************
SUB TRANS BOARD
****************
1-533-217-41 HOLDER, FUSE (E3,E15,PH)
< CAPACITOR >
C902 1-164-159-11 CERAMIC 0.1uF 50V
C903 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN902 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< COIL >
L901 1-414-189-31 INDUCTOR 100uH
PANEL
