85
HCD-GNZ5D
Ref. No. Part No. Description Remark
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R901 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
0 RY901 1-755-324-11 RELAY
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E3,E15,PH)
*************************************************************
1-687-669-12 SW BOARD
**********
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE DET)
*************************************************************
TRANS BOARD
*************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C912 1-126-960-11 ELECT 1uF 20% 50V
(E12,E13)
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
C918 1-128-576-11 ELECT 100uF 20% 63V
< CONNECTOR >
* CN914 1-564-525-11 PLUG, CONNECTOR 10P
* CN915 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 8-719-982-19 DIODE MTZJ-30A
D913 8-719-118-64 DIODE RD5.6F-T7B3
< TRANSISTOR >
Q902 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
0 R911 1-217-637-00 FUSIBLE 1 5% 1/4W F
R914 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R919 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
A-1109-328-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C801 1-104-655-11 ELECT 470uF 20% 6.3V
C802 1-162-306-11 CERAMIC 0.01uF 20% 16V
C811 1-126-960-11 ELECT 1uF 20% 50V
C812 1-126-916-11 ELECT 1000uF 20% 6.3V
C813 1-162-282-31 CERAMIC 100PF 10% 50V
C840 1-162-282-31 CERAMIC 100PF 10% 50V
C841 1-162-282-31 CERAMIC 100PF 10% 50V
C842 1-162-282-31 CERAMIC 100PF 10% 50V
C850 1-126-942-61 ELECT 1000uF 20% 25V
C851 1-164-159-11 CERAMIC 0.1uF 50V
C852 1-117-245-11 ELECT 330uF 20% 6.3V
C853 1-126-960-11 ELECT 1uF 20% 50V
C854 1-164-159-11 CERAMIC 0.1uF 50V
C856 1-117-245-11 ELECT 330uF 20% 6.3V
C862 1-117-317-11 ELECT 1000uF 20% 25V
C863 1-128-646-11 ELECT 1000uF 20% 6.3V
C865 1-117-245-11 ELECT 330uF 20% 6.3V
C866 1-117-245-11 ELECT 330uF 20% 6.3V
C872 1-164-159-11 CERAMIC 0.1uF 50V
C873 1-104-658-11 ELECT 100uF 20% 10V
< CONNECTOR >
CN801 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
* CN851 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
< DIODE >
D861 8-719-210-21 DIODE 11EQS04
< GROUND TERMINAL >
EP801 1-537-771-21 TERMINAL BOARD, GROUND
EP851 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC801 6-600-495-01 IC MM1671XNRE
IC851 6-705-463-01 IC BA33BC0T
IC861 8-759-474-09 IC SI-8050S-LF1101
< JACK >
J801 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L801 1-410-470-11 INDUCTOR 10uH
L861 1-456-513-11 INDUCTOR 150uH
L862 1-414-741-11 INDUCTOR 10uH
< TRANSISTOR >
Q861 8-729-029-66 TRANSISTOR DTC114ESA
Q870 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R801 1-249-429-11 CARBON 10K 5% 1/4W
R811 1-247-804-11 CARBON 75 5% 1/4W
R812 1-247-879-11 CARBON 100K 5% 1/4W
Ref. No. Part No. Description Remark
