100
HCD-GNZ7D/GNZ8D/GNZ9D
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R919 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
A-1095-819-A VIDEO BOARD, COMPLETE (EXCEPT TH)
A-1111-533-A VIDEO BOARD, COMPLETE (TH)
*********************
< CAPACITOR >
C801 1-104-655-11 ELECT 470uF 20% 6.3V
C802 1-162-306-11 CERAMIC 0.01uF 20% 16V
C803 1-104-658-11 ELECT 100uF 20% 10V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C811 1-126-960-11 ELECT 1uF 20% 50V
C812 1-126-960-11 ELECT 1uF 20% 50V
C813 1-126-960-11 ELECT 1uF 20% 50V
C814 1-126-960-11 ELECT 1uF 20% 50V
C815 1-126-960-11 ELECT 1uF 20% 50V
C816 1-126-960-11 ELECT 1uF 20% 50V
C818 1-126-960-11 ELECT 1uF 20% 50V
C819 1-126-916-11 ELECT 1000uF 20% 6.3V
C820 1-126-916-11 ELECT 1000uF 20% 6.3V
C821 1-126-916-11 ELECT 1000uF 20% 6.3V
C822 1-126-916-11 ELECT 1000uF 20% 6.3V
C823 1-164-159-11 CERAMIC 0.1uF 50V
C824 1-126-916-11 ELECT 1000uF 20% 6.3V
C825 1-162-282-31 CERAMIC 100PF 10% 50V
C831 1-162-306-11 CERAMIC 0.01uF 20% 16V
C832 1-126-960-11 ELECT 1uF 20% 50V
C833 1-162-282-31 CERAMIC 100PF 10% 50V
C835 1-104-658-11 ELECT 100uF 20% 10V
C840 1-162-282-31 CERAMIC 100PF 10% 50V
C841 1-162-282-31 CERAMIC 100PF 10% 50V
C842 1-162-282-31 CERAMIC 100PF 10% 50V
C843 1-162-282-31 CERAMIC 100PF 10% 50V
C844 1-162-282-31 CERAMIC 100PF 10% 50V
C850 1-126-942-61 ELECT 1000uF 20% 25V
C851 1-164-159-11 CERAMIC 0.1uF 50V
C852 1-117-245-11 ELECT 330uF 20% 6.3V
C853 1-126-960-11 ELECT 1uF 20% 50V
C854 1-164-159-11 CERAMIC 0.1uF 50V
C856 1-117-245-11 ELECT 330uF 20% 6.3V
C862 1-117-317-11 ELECT 1000uF 20% 25V
C863 1-128-646-11 ELECT 1000uF 20% 6.3V
C865 1-117-245-11 ELECT 330uF 20% 6.3V
C866 1-117-245-11 ELECT 330uF 20% 6.3V
C872 1-164-159-11 CERAMIC 0.1uF 50V
C873 1-104-658-11 ELECT 100uF 20% 10V
< CONNECTOR >
CN801 1-779-281-11 CONNECTOR, FFC (LIF(NON-ZIF)) 13P
* CN851 1-564-728-11 PIN, CONNECTOR (SMALL TYPE) 12P
< DIODE >
D861 8-719-210-21 DIODE 11EQS04
< GROUND TERMINAL >
EP801 1-537-771-21 TERMINAL BOARD, GROUND
EP851 1-537-771-21 TERMINAL BOARD, GROUND
< COIL >
FB831 1-412-473-21 INDUCTOR (SMALL TYPE)
< IC >
IC801 6-705-602-01 IC MM1623BFBE
IC802 6-703-622-01 IC MM1508XNRE
IC851 6-705-463-01 IC BA33BC0T
IC861 8-759-474-09 IC SI-8050S-LF1101
< JACK >
J801 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J802 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< CONNECTOR >
J803 1-784-248-11 CONNECTOR (ROUND TYPE) (S VIDEO OUT)
< COIL >
L801 1-410-470-11 INDUCTOR 10uH
L802 1-410-470-11 INDUCTOR 10uH
L861 1-456-513-11 INDUCTOR 150uH
L862 1-414-741-11 INDUCTOR 10uH
< TRANSISTOR >
Q861 8-729-029-66 TRANSISTOR DTC114ESA
Q870 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R800 1-247-807-31 CARBON 100 5% 1/4W
R803 1-249-429-11 CARBON 10K 5% 1/4W
R804 1-249-429-11 CARBON 10K 5% 1/4W
R805 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-249-429-11 CARBON 10K 5% 1/4W
R810 1-247-804-11 CARBON 75 5% 1/4W
R811 1-247-804-11 CARBON 75 5% 1/4W
R812 1-247-804-11 CARBON 75 5% 1/4W
R813 1-247-804-11 CARBON 75 5% 1/4W
R814 1-247-804-11 CARBON 75 5% 1/4W
R815 1-247-804-11 CARBON 75 5% 1/4W
R816 1-247-804-11 CARBON 75 5% 1/4W
R817 1-247-804-11 CARBON 75 5% 1/4W
R818 1-247-879-11 CARBON 100K 5% 1/4W
R831 1-247-807-31 CARBON 100 5% 1/4W
R870 1-247-807-31 CARBON 100 5% 1/4W
R871 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
MISCELLANEOUS
**************
6 1-828-956-11 WIRE (FLAT TYPE) (9 CORE)
55 1-828-977-11 WIRE (FLAT TYPE) (13 CORE)
56 1-828-971-11 WIRE (FLAT TYPE) (13 CORE)
57 1-829-041-11 WIRE (FLAT TYPE) (27 CORE)
58 1-797-246-11 DECK, MECHANISM
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
