99
HCD-GNZ7D/GNZ8D/GNZ9D
R532 1-247-873-11 CARBON 56K 5% 1/4W
(GNZ8D/GNZ9D)
R533 1-249-439-11 CARBON 68K 5% 1/4W
(GNZ8D/GNZ9D)
R541 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ8D/GNZ9D)
R542 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ8D/GNZ9D)
R543 1-249-416-11 CARBON 820 5% 1/4W
(GNZ9D)
R543 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ8D)
R544 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ8D/GNZ9D)
0 R545 1-208-602-11 METAL 0.22X2 2W F
(GNZ8D/GNZ9D)
R547 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ8D/GNZ9D)
R548 1-249-431-11 CARBON 15K 5% 1/4W
(GNZ8D/GNZ9D)
R549 1-247-879-11 CARBON 100K 5% 1/4W
(GNZ8D/GNZ9D)
0 R550 1-260-076-11 CARBON 10 5% 1/2W F
(GNZ8D/GNZ9D)
R551 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ8D/GNZ9D)
R552 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ8D/GNZ9D)
R553 1-249-415-11 CARBON 680 5% 1/4W
(GNZ9D)
R553 1-249-416-11 CARBON 820 5% 1/4W
(GNZ8D)
R554 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ8D/GNZ9D)
0 R555 1-208-602-11 METAL 0.22X2 2W F
(GNZ8D/GNZ9D)
R557 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ8D/GNZ9D)
R558 1-249-431-11 CARBON 15K 5% 1/4W
(GNZ8D/GNZ9D)
R559 1-247-879-11 CARBON 100K 5% 1/4W
(GNZ8D/GNZ9D)
0 R560 1-260-076-11 CARBON 10 5% 1/2W F
(GNZ8D/GNZ9D)
0 R561 1-212-881-11 FUSIBLE 100 5% 1/4W F
(GNZ8D/GNZ9D)
R573 1-247-879-11 CARBON 100K 5% 1/4W
(GNZ8D/GNZ9D)
R574 1-247-879-11 CARBON 100K 5% 1/4W
(GNZ8D/GNZ9D)
R587 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ8D/GNZ9D)
R588 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ8D/GNZ9D)
R589 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ8D/GNZ9D)
R590 1-249-429-11 CARBON 10K 5% 1/4W
(GNZ8D/GNZ9D)
R593 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ9D)
0 R594 1-215-888-00 METAL OXIDE 220 5% 2W F
(GNZ8D)
0R594 1-216-455-11 METAL OXIDE 560 5% 2W F
(GNZ9D)
R597 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ8D/GNZ9D)
R598 1-247-863-11 CARBON 22K 5% 1/4W
(GNZ8D/GNZ9D)
0R599 1-215-888-00 METAL OXIDE 220 5% 2W F
(GNZ8D)
0R599 1-216-455-11 METAL OXIDE 560 5% 2W F
(GNZ9D)
< RELAY >
RY581 1-515-920-11 RELAY (24V) (GNZ8D/GNZ9D)
RY582 1-515-920-11 RELAY (24V) (GNZ8D/GNZ9D)
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR 10K (GNZ8D/GNZ9D)
< TERMINAL BOARD >
TM501 1-694-674-22 TERMINAL BOARD (6P) (SURROUND SPEAKER)
(GNZ8D)
TM501 1-694-914-11 TERMINAL BOARD (8P) (SURROUND SPEAKER)
(GNZ9D)
*************************************************************
1-687-669-12 SW BOARD
*********
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE)
(OPEN/CLOSE DETECT)
*************************************************************
TRANS BOARD
************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
C918 1-128-576-11 ELECT 100uF 20% 63V
< CONNECTOR >
* CN913 1-564-518-11 PLUG, CONNECTOR 3P (GNZ8D/GNZ9D)
* CN914 1-564-525-11 PLUG, CONNECTOR 10P
* CN915 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 8-719-982-19 DIODE MTZJ-30A
D913 8-719-118-67 DIODE RD6.2F-T7B3
< TRANSISTOR >
Q902 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
0R911 1-217-637-00 FUSIBLE 1 5% 1/4W F
R914 1-249-429-11 CARBON 10K 5% 1/4W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
