93
HCD-GNZ7D/GNZ8D/GNZ9D
1-687-134-12 MOTOR (TB) BOARD
****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
*************************************************************
A-1095-804-A PANEL BOARD, COMPLETE (EXCEPT TH)
A-1111-502-A PANEL BOARD, COMPLETE (TH)
*********************
< CAPACITOR >
C101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C102 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C103 1-126-916-11 ELECT 1000uF 20% 6.3V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-119-941-11 ELECT 470uF 20% 6.3V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C111 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C113 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C114 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C115 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C116 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C117 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C118 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C119 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C120 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C121 1-119-941-11 ELECT 470uF 20% 6.3V
C122 1-119-941-11 ELECT 470uF 20% 6.3V
C125 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C126 1-119-943-11 ELECT 47uF 20% 50V
C127 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C128 1-126-382-11 ELECT 100uF 20% 16V
C129 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C130 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C144 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C145 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C146 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C147 1-126-382-11 ELECT 100uF 20% 16V
C152 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C153 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C154 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN001 1-568-450-11 HOUSING, CONNECTOR (PC BOARD) 4P
* CN002 1-568-451-11 HOUSING, CONNECTOR (PC BOARD) 10P
CN003 1-784-749-11 CONNECTOR, FFC 27P
CN004 1-784-735-11 CONNECTOR, FFC 13P
CN005 1-779-550-21 CONNECTOR, FFC (LIF(NON-ZIF)) 13P
CN102 1-784-735-11 CONNECTOR, FFC 13P
CN151 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P
CN152 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
CN153 1-818-282-11 PIN, CONNECTOR (FOR PWB) 3P
< DIODE >
D101 6-500-335-01 DIODE MC2838-T112-1
D102 6-500-335-01 DIODE MC2838-T112-1
D105 8-719-988-61 DIODE 1SS355TE-17
D106 8-719-988-61 DIODE 1SS355TE-17
D107 8-719-988-61 DIODE 1SS355TE-17
D108 1-216-295-11 SHORT CHIP 0
D109 8-719-988-61 DIODE 1SS355TE-17
D110 8-719-053-43 LED SLR-325VCT31 (`/1)
D111 8-719-988-61 DIODE 1SS355TE-17
D112 8-719-988-61 DIODE 1SS355TE-17
D113 8-719-988-61 DIODE 1SS355TE-17
D114 8-719-988-61 DIODE 1SS355TE-17
D121 8-719-988-61 DIODE 1SS355TE-17
< JUMPER RESISTOR >
FB101 1-216-295-11 SHORT CHIP 0
FB102 1-216-295-11 SHORT CHIP 0
FB103 1-216-295-11 SHORT CHIP 0
FB104 1-216-295-11 SHORT CHIP 0
FB105 1-216-295-11 SHORT CHIP 0
< FLUORESCENT INDICATOR >
FL101 1-519-811-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 6-805-164-01 IC M30392MEP-A00FPU5
IC102 6-707-095-01 IC BH2210FV-E2
IC103 6-707-920-01 IC BD4828G-TR
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR107 1-216-864-11 SHORT CHIP 0
JR108 1-216-864-11 SHORT CHIP 0
JR109 1-216-864-11 SHORT CHIP 0
JR110 1-216-864-11 SHORT CHIP 0
JR111 1-216-864-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR119 1-216-864-11 SHORT CHIP 0
JR120 1-216-864-11 SHORT CHIP 0
JR121 1-216-864-11 SHORT CHIP 0
JR123 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q101 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327
Q102 6-550-044-01 TRANSISTOR 2SB1689-T106
Q103 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327
Q104 6-550-044-01 TRANSISTOR 2SB1689-T106
Q105 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327
Q106 6-550-044-01 TRANSISTOR 2SB1689-T106
Q107 8-729-905-35 TRANSISTOR 2SC4081-R
Q108 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327
Q109 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q111 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327
Q112 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327
Q113 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MOTOR (TB) PANEL
