92
HCD-GNZ7D/GNZ8D/GNZ9D
Ref. No. Part No. Description Remark
A-1095-805-A JACK BOARD, COMPLETE (EXCEPT TH)
A-1111-503-A JACK BOARD, COMPLETE (TH)
********************
< CAPACITOR >
C1001 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1002 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1003 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C1004 1-126-791-11 ELECT 10uF 20% 35V
C1005 1-115-872-11 ELECT 2.2uF 20% 50V
C1006 1-162-955-11 CERAMIC CHIP 150PF 5% 50V
C1007 1-126-786-11 ELECT 47uF 20% 16V
C1008 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C1009 1-115-872-11 ELECT 2.2uF 20% 50V
C1010 1-115-867-11 ELECT 0.1uF 20% 50V
C1011 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1012 1-126-786-11 ELECT 47uF 20% 16V
C1013 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C1014 1-115-868-11 ELECT 0.22uF 20% 50V
C1015 1-115-868-11 ELECT 0.22uF 20% 50V
C1016 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C1017 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C1018 1-131-664-11 CERAMIC CHIP 0.15uF 10% 10V
C1019 1-115-871-11 ELECT 1uF 20% 50V
C1020 1-115-871-11 ELECT 1uF 20% 50V
C1021 1-115-870-11 ELECT 0.47uF 20% 50V
C1022 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1023 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C1024 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1025 1-115-870-11 ELECT 0.47uF 20% 50V
C1026 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C1027 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C1028 1-126-785-11 ELECT 47uF 20% 10V
C1029 1-115-872-11 ELECT 2.2uF 20% 50V
C1030 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C1031 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1034 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C1035 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C1036 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< DIODE >
D1001 8-719-988-61 DIODE 1SS355TE-17
D1002 8-719-988-61 DIODE 1SS355TE-17
D1003 8-719-988-61 DIODE 1SS355TE-17
D1004 8-719-988-61 DIODE 1SS355TE-17
D1005 8-719-988-61 DIODE 1SS355TE-17
D1006 8-719-988-61 DIODE 1SS355TE-17
D1007 8-719-083-58 DIODE UDZSTE-173.9B
< GROUND TERMINAL >
EPT1001 1-537-771-21 TERMINAL BOARD, GROUND
EPT1002 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB1001 1-469-869-21 INDUCTOR (EMI FERRITE) (2012)
FB1002 1-216-295-11 SHORT CHIP 0
FB1003 1-216-295-11 SHORT CHIP 0
FB1004 1-216-295-11 SHORT CHIP 0
< IC >
IC1001 8-759-710-97 IC NJM4565M-D
IC1002 8-759-496-41 IC M65850FP-E1
< JACK >
J1001 1-764-592-11 JACK, PIN 3P (VIDEO INPUT)
J1002 1-770-226-11 JACK (LARGE TYPE) (MIC 2)
J1003 1-770-226-11 JACK (LARGE TYPE) (MIC 1)
J1004 1-794-702-11 JACK, HEADPHONE (PHONES)
< JUMPER RESISTOR >
JR1000 1-216-295-11 SHORT CHIP 0
JW1001 1-216-295-11 SHORT CHIP 0
< RESISTOR >
R1000 1-218-285-11 METAL CHIP 75 5% 1/10W
R1001 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1002 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1003 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1004 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1005 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1006 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1007 1-216-813-11 METAL CHIP 220 5% 1/10W
R1008 1-216-809-11 METAL CHIP 100 5% 1/10W
R1009 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R1010 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1011 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1012 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1013 1-216-809-11 METAL CHIP 100 5% 1/10W
R1014 1-216-851-11 METAL CHIP 330K 5% 1/10W
R1015 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1016 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1017 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1018 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1021 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1022 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1023 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1024 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1025 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1026 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1027 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1028 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1029 1-216-846-11 METAL CHIP 120K 5% 1/10W
R1030 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1031 1-260-083-11 CARBON 47 5% 1/2W F
R1032 1-260-083-11 CARBON 47 5% 1/2W F
< VARIABLE RESISTOR >
RV1001 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV1002 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
*************************************************************
1-687-133-12 MOTOR (LD) BOARD
****************
*************************************************************
Ref. No. Part No. Description Remark
JACK MOTOR (LD)
