91
HCD-GNZ7D/GNZ8D/GNZ9D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C485 1-162-306-11 CERAMIC 0.01uF 20% 16V
C486 1-162-306-11 CERAMIC 0.01uF 20% 16V
C941 1-126-956-11 ELECT 0.1uF 20% 50V
C942 1-126-925-11 ELECT 470uF 20% 10V
C943 1-126-956-11 ELECT 0.1uF 20% 50V
C944 1-104-658-11 ELECT 100uF 20% 10V
C945 1-126-956-11 ELECT 0.1uF 20% 50V
C946 1-104-658-11 ELECT 100uF 20% 10V
C949 1-126-947-11 ELECT 47uF 20% 35V
C950 1-104-658-11 ELECT 100uF 20% 10V
< CONNECTOR >
CN401 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN402 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN403 1-564-506-11 PLUG, CONNECTOR 3P (GNZ9D)
CN404 1-564-507-11 PLUG, CONNECTOR 4P (GNZ9D)
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D410 8-719-210-21 DIODE 11EQS04
D451 8-719-991-33 DIODE 1SS133T-77
D471 8-719-022-99 DIODE D6SB60L (GNZ9D)
D471 8-719-510-68 DIODE D5SBA204101 (GNZ7D/GNZ8D)
D481 8-719-991-33 DIODE 1SS133T-77
D485 8-719-991-33 DIODE 1SS133T-77
D486 8-719-991-33 DIODE 1SS133T-77
D491 8-719-991-33 DIODE 1SS133T-77
< IC >
IC401 6-600-221-01 IC STK403-130 (GNZ9D)
IC401 6-705-853-01 IC STK403-120 (GNZ7D/GNZ8D)
< TRANSISTOR >
Q401 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q402 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q403 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q416 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q417 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q451 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q481 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q482 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R401 1-247-831-11 CARBON 1K 5% 1/4W
R402 1-247-871-11 CARBON 47K 5% 1/4W
R403 1-247-807-31 CARBON 100 5% 1/4W
(GNZ7D)
R403 1-249-407-11 CARBON 150 5% 1/4W
(GNZ9D)
R403 1-249-408-11 CARBON 180 5% 1/4W
(GNZ8D)
R404 1-247-871-11 CARBON 47K 5% 1/4W
0 R406 1-208-602-11 METAL 0.22X2 2W F
R407 1-247-831-11 CARBON 1K 5% 1/4W
R408 1-249-431-11 CARBON 15K 5% 1/4W
R409 1-247-879-11 CARBON 100K 5% 1/4W
R410 1-260-076-11 CARBON 10 5% 1/2W F
0 R411 1-212-881-11 FUSIBLE 100 5% 1/4W F
R412 1-247-887-00 CARBON 220K 5% 1/4W
R413 1-249-421-11 CARBON 2.2K 5% 1/4W
R415 1-249-429-11 CARBON 10K 5% 1/4W
R416 1-249-429-11 CARBON 10K 5% 1/4W
R417 1-249-429-11 CARBON 10K 5% 1/4W
R418 1-247-871-11 CARBON 47K 5% 1/4W
0R419 1-202-972-61 FUSIBLE 1 5% 1/4W F
0R420 1-202-972-61 FUSIBLE 1 5% 1/4W F
R421 1-249-429-11 CARBON 10K 5% 1/4W
R425 1-249-439-11 CARBON 68K 5% 1/4W
R426 1-249-426-11 CARBON 5.6K 5% 1/4W
R427 1-249-421-11 CARBON 2.2K 5% 1/4W
R428 1-247-863-11 CARBON 22K 5% 1/4W
R429 1-249-429-11 CARBON 10K 5% 1/4W
R430 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-247-871-11 CARBON 47K 5% 1/4W
R440 1-247-873-11 CARBON 56K 5% 1/4W
R451 1-247-831-11 CARBON 1K 5% 1/4W
R452 1-247-871-11 CARBON 47K 5% 1/4W
R453 1-247-807-31 CARBON 100 5% 1/4W
(GNZ7D)
R453 1-249-407-11 CARBON 150 5% 1/4W
(GNZ9D)
R453 1-249-408-11 CARBON 180 5% 1/4W
(GNZ8D)
R454 1-247-871-11 CARBON 47K 5% 1/4W
0R456 1-208-602-11 METAL 0.22X2 2W F
R457 1-247-831-11 CARBON 1K 5% 1/4W
R458 1-249-431-11 CARBON 15K 5% 1/4W
R459 1-247-879-11 CARBON 100K 5% 1/4W
R460 1-260-076-11 CARBON 10 5% 1/2W F
0R461 1-212-881-11 FUSIBLE 100 5% 1/4W F
R471 1-247-879-11 CARBON 100K 5% 1/4W
R472 1-247-879-11 CARBON 100K 5% 1/4W
0R480 1-215-892-11 METAL OXIDE 1K 5% 2W F
(GNZ8D)
0R480 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(GNZ7D/GNZ9D)
R485 1-247-871-11 CARBON 47K 5% 1/4W
R486 1-247-871-11 CARBON 47K 5% 1/4W
R487 1-249-429-11 CARBON 10K 5% 1/4W
R488 1-247-871-11 CARBON 47K 5% 1/4W
R489 1-249-429-11 CARBON 10K 5% 1/4W
R490 1-249-429-11 CARBON 10K 5% 1/4W
R941 1-247-831-11 CARBON 1K 5% 1/4W
< RELAY >
RY481 1-515-920-11 RELAY (24V)
< THERMISTOR >
TH401 1-807-796-11 THERMISTOR 10K
< TERMINAL BOARD >
TM401 1-694-677-12 TERMINAL BOARD (4P) (FRONT SPEAKER)
*************************************************************
FRONT AMP
