90
HCD-GNZ7D/GNZ8D/GNZ9D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R3788 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3789 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3801 1-216-864-11 SHORT CHIP 0
R3802 1-216-864-11 SHORT CHIP 0
R3803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3804 1-216-836-11 METAL CHIP 18K 5% 1/10W
R3805 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
R5003 1-216-864-11 SHORT CHIP 0 (GNZ7D)
R5004 1-216-864-11 SHORT CHIP 0 (GNZ8D/GNZ9D)
R5011 1-216-864-11 SHORT CHIP 0
R5014 1-216-864-11 SHORT CHIP 0 (E2,E51,MX)
R5016 1-216-864-11 SHORT CHIP 0 (E3,E12,E13,E15,AUS,EA)
R5017 1-216-864-11 SHORT CHIP 0 (PH,SP,TH)
< NETWORK RESISTOR >
RB103 1-234-795-21 RES, NETWORK 0X4 (2010)
RB104 1-234-795-21 RES, NETWORK 0X4 (2010)
RB105 1-234-371-21 RES, NETWORK 47X4 (1005)
RB106 1-234-371-21 RES, NETWORK 47X4 (1005)
RB107 1-234-370-21 RES, NETWORK 22X4 (1005)
RB108 1-234-370-21 RES, NETWORK 22X4 (1005)
RB111 1-234-795-21 RES, NETWORK 0X4 (2010)
RB112 1-234-370-21 RES, NETWORK 22X4 (1005)
RB113 1-234-370-21 RES, NETWORK 22X4 (1005)
< VIBRATOR >
X101 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
*************************************************************
A-1103-756-A DRIVER BOARD, COMPLETE
**********************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-21 CERAMIC 0.1uF 50V
C736 1-164-159-21 CERAMIC 0.1uF 50V
C737 1-164-159-21 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 20% 16V
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C752 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-735-11 CONNECTOR, FFC 13P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
< DIODE >
D701 8-719-921-42 DIODE MTZJ-5.1A
D711 8-719-109-69 DIODE RD3.6ESB2
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W
R722 1-249-425-11 CARBON 4.7K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W
*************************************************************
A-1095-771-A FRONT AMP BOARD, COMPLETE
(GNZ9D:EXCEPT TH)
A-1095-772-A FRONT AMP BOARD, COMPLETE
(GNZ8D:EXCEPT TH)
A-1095-773-A FRONT AMP BOARD, COMPLETE
(GNZ7D:EXCEPT TH)
A-1111-483-A FRONT AMP BOARD, COMPLETE (GNZ9D:TH)
A-1111-484-A FRONT AMP BOARD, COMPLETE (GNZ8D:TH)
A-1111-485-A FRONT AMP BOARD, COMPLETE (GNZ7D:TH)
*************************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C401 1-126-964-11 ELECT 10uF 20% 50V
C402 1-162-294-31 CERAMIC 0.001uF 10% 50V
C403 1-162-286-31 CERAMIC 220PF 10% 50V
C404 1-126-967-11 ELECT 47uF 20% 50V
(GNZ8D/GNZ9D)
C404 1-126-968-11 ELECT 100uF 20% 50V
(GNZ7D)
C406 1-136-495-11 FILM 0.068uF 5% 50V
C407 1-136-495-11 FILM 0.068uF 5% 50V
C408 1-128-576-11 ELECT 100uF 20% 63V
C410 1-126-926-11 ELECT 1000uF 20% 10V
C416 1-162-306-11 CERAMIC 0.01uF 20% 16V
C421 1-126-966-11 ELECT 33uF 20% 50V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-162-294-31 CERAMIC 0.001uF 10% 50V
C453 1-162-286-31 CERAMIC 220PF 10% 50V
C454 1-126-967-11 ELECT 47uF 20% 50V
(GNZ8D/GNZ9D)
C454 1-126-968-11 ELECT 100uF 20% 50V
(GNZ7D)
C456 1-136-495-11 FILM 0.068uF 5% 50V
C457 1-136-495-11 FILM 0.068uF 5% 50V
C458 1-128-576-11 ELECT 100uF 20% 63V
C471 1-135-928-21 ELECT 2200uF 20% 63V
C472 1-135-928-21 ELECT 2200uF 20% 63V
DRIVER FRONT AMPDMB10
Ver. 1.1
