Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
127
HCD-M700
C919 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
(AEP,UK)
C920 1-128-551-11 ELECT 22uF 20.00% 25V
C921 1-126-767-11 ELECT 1000uF 20.00% 16V
C922 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
(AEP,UK)
C923 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
(AEP,UK)
C924 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
(AEP,UK)
C925 1-126-944-11 ELECT 3300uF 20.00% 25V
C926 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C927 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C928 1-126-964-11 ELECT 10uF 20.00% 50V
C929 1-117-298-91 ELECT 330uF 20.00% 16V
C930 1-117-339-91 ELECT 22uF 20.00% 35V
C931 1-117-245-91 ELECT 330uF 20.00% 6.3V
C932 1-117-339-91 ELECT 22uF 20.00% 35V
C933 1-117-245-91 ELECT 330uF 20.00% 6.3V
C934 1-117-339-91 ELECT 22uF 20.00% 35V
C935 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
(AEP,UK)
C936 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
(AEP,UK)
C937 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
(AEP,UK)
C938 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
(AEP,UK)
C939 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
(AEP,UK)
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P
CN902 1-766-284-11 PIN, CONNECTOR (PC BOARD) 11P
CN903 1-568-955-11 PIN, CONNECTOR 6P
< DIODE >
D902 8-719-902-17 DIODE 1N5401
D903 8-719-902-17 DIODE 1N5401
D904 8-719-902-17 DIODE 1N5401
D905 8-719-902-17 DIODE 1N5401
D906 8-719-046-07 DIODE 2A02M
D907 8-719-046-07 DIODE 2A02M
D908 8-719-046-07 DIODE 2A02M
D909 8-719-046-07 DIODE 2A02M
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-991-33 DIODE 1SS133T-77
D912 8-719-991-33 DIODE 1SS133T-77
D913 8-719-991-33 DIODE 1SS133T-77
D914 8-719-046-07 DIODE 2A02M
D915 8-719-046-07 DIODE 2A02M
D916 8-719-046-07 DIODE 2A02M
D917 8-719-046-07 DIODE 2A02M
D918 8-719-109-93 DIODE MTZJ-T-77-6.2B
D919 8-719-991-33 DIODE 1SS133T-77
D920 8-719-991-33 DIODE 1SS133T-77
D921 8-719-991-33 DIODE 1SS133T-77
D923 8-719-921-63 DIODE MTZJ-T-77-7.5B
D924 8-719-210-21 DIODE 11EQS04-TA1B
D925 8-719-210-21 DIODE 11EQS04-TA1B
D926 8-719-210-21 DIODE 11EQS04-TA1B
< IC >
IC901 6-701-021-01 IC SI-8120JF
IC902 6-700-812-01 IC SI-8050JF
IC903 6-700-813-01 IC SI-8033JF
IC904 6-701-760-01 IC uPC3504AHF
< JUMPER RESISTOR >
JR905 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
0L901 1-416-909-11 INDUCTOR 100uH
0L902 1-416-909-11 INDUCTOR 100uH
0L903 1-416-909-11 INDUCTOR 100uH
< LINE FILTER >
0LF901 1-424-150-11 TRANSFORMER, LINE FILTER
< TRANSISTOR >
Q902 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q904 8-729-055-94 TRANSISTOR SRC1202SF
Q905 8-729-056-23 TRANSISTOR STC352-OY
Q906 8-729-055-91 TRANSISTOR SRA2202SF
Q907 8-729-055-94 TRANSISTOR SRC1202SF
< RESISTOR >
R901 1-249-385-11 CARBON 2.2 5% 1/6W F
R903 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R904 1-216-841-11 METAL CHIP 47K 5% 1/16W
R905 1-249-417-11 CARBON 1K 5% 1/4W F
R906 1-249-417-11 CARBON 1K 5% 1/4W F
R908 1-216-864-11 METAL CHIP 0 5% 1/16W
R909 1-216-864-11 METAL CHIP 0 5% 1/16W
R912 1-249-417-11 CARBON 1K 5% 1/4W F
R913 1-249-417-11 CARBON 1K 5% 1/4W F
R914 1-216-821-11 METAL CHIP 1K 5% 1/16W
R915 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
< RELAY >
0RY901 1-755-332-11 RELAY
< SWITCH >
0S901 1-786-152-11 SWITCH, SLIDE (VOLTAGE SELECTOR) (HK)
< TRANSFORMER >
0T901 1-437-730-11 TRANSFORMER, POWER (AEP,UK)
0T901 1-437-844-11 TRANSFORMER, POWER (HK)
*************************************************************
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
