Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
128
HCD-M700
A-4728-685-A RF-240 BOARD, COMPLETE
**********************
< CAPACITOR >
C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C005 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C006 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C007 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C008 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C009 1-124-779-00 ELECT CHIP 10uF 20% 16V
C015 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C016 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C017 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C018 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C019 1-164-739-11 CERAMIC CHIP 560PF 5.00% 50V
C021 1-124-779-00 ELECT CHIP 10uF 20% 16V
C022 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C023 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C024 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C026 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C027 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C028 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C032 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C033 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C034 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C036 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C038 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C039 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C040 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C043 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C044 1-124-779-00 ELECT CHIP 10uF 20% 16V
C046 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C047 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C048 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN001 1-766-835-21 CONNECTOR, FFC/FPC (ZIF) 26P
CN002 1-784-875-21 CONNECTOR,FFC(LIF(NON-ZIF))25P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D004 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 8-759-828-02 IC SP3728AC
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R002 1-216-809-11 METAL CHIP 100 5% 1/16W
R003 1-216-809-11 METAL CHIP 100 5% 1/16W
R005 1-216-845-11 METAL CHIP 100K 5% 1/16W
R006 1-216-838-11 METAL CHIP 27K 5% 1/16W
R007 1-216-803-11 METAL CHIP 33 5% 1/16W
R008 1-216-803-11 METAL CHIP 33 5% 1/16W
R009 1-216-821-11 METAL CHIP 1K 5% 1/16W
R010 1-216-841-11 METAL CHIP 47K 5% 1/16W
R011 1-216-809-11 METAL CHIP 100 5% 1/16W
R020 1-216-803-11 METAL CHIP 33 5% 1/16W
R023 1-216-803-11 METAL CHIP 33 5% 1/16W
R025 1-216-841-11 METAL CHIP 47K 5% 1/16W
R029 1-216-809-11 METAL CHIP 100 5% 1/16W
R037 1-216-834-11 METAL CHIP 12K 5% 1/16W
R038 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R045 1-216-809-11 METAL CHIP 100 5% 1/16W
**************************************************************
A-4728-710-A SWITCH BOARD, COMPLETE
***********************
4-239-591-02 LCD, HOLDER
4-239-594-02 PLATE (LCD LIGHT)
4-239-610-02 SHEET (LCD)
< CAPACITOR >
C801 1-126-157-11 ELECT 10uF 20% 16V
C802 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C841 1-126-163-11 ELECT 4.7uF 20% 50V
C842 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C874 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C875 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C877 1-126-160-11 ELECT 1uF 20% 50V
C878 1-126-160-11 ELECT 1uF 20% 50V
< CONNECTOR >
CN801 1-784-741-11 CONNECTOR, FFC 19P
< DIODE >
D805 8-719-058-04 DIODE SEL5223S-TP15
D806 8-719-058-64 DIODE SEL5823A-TP15
D807 8-719-058-64 DIODE SEL5823A-TP15
D808 8-719-058-64 DIODE SEL5823A-TP15
D809 8-719-058-64 DIODE SEL5823A-TP15
D813 8-719-058-64 DIODE SEL5823A-TP15
D814 8-719-058-64 DIODE SEL5823A-TP15
D818 6-500-083-01 DIODE NSPW315BSRS
D819 6-500-083-01 DIODE NSPW315BSRS
D820 6-500-083-01 DIODE NSPW315BSRS
< IC >
IC801 8-759-826-34 IC NJL74H400A
< JUMPER RESISTOR >
JR802 1-216-864-11 METAL CHIP 0 5% 1/16W
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
RF-240 SWITCH
