Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
130
HCD-M700
< IC >
IC401 6-701-655-01 IC HA12236F
< JUMPER RESISTOR >
JR102 1-216-864-11 METAL CHIP 0 5% 1/16W
JR103 1-216-864-11 METAL CHIP 0 5% 1/16W
JR104 1-216-864-11 METAL CHIP 0 5% 1/16W
JR105 1-216-821-11 METAL CHIP 1K 5% 1/16W
JR106 1-216-821-11 METAL CHIP 1K 5% 1/16W
JR201 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q100 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q101 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q200 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q201 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q401 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q402 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q403 8-729-038-67 TRANSISTOR KRC102S
Q404 8-759-068-54 TRANSISTOR KRA102S
Q405 8-729-038-71 TRANSISTOR KRC107S
< RESISTOR >
R101 1-216-841-11 METAL CHIP 47K 5% 1/16W
R102 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R103 1-216-833-11 METAL CHIP 10K 5% 1/16W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R105 1-216-841-11 METAL CHIP 47K 5% 1/16W
R106 1-216-833-11 METAL CHIP 10K 5% 1/16W
R107 1-216-833-11 METAL CHIP 10K 5% 1/16W
R108 1-216-833-11 METAL CHIP 10K 5% 1/16W
R109 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R111 1-216-833-11 METAL CHIP 10K 5% 1/16W
R112 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R113 1-216-797-11 METAL CHIP 10 5% 1/16W
R201 1-216-841-11 METAL CHIP 47K 5% 1/16W
R202 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R203 1-216-833-11 METAL CHIP 10K 5% 1/16W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R205 1-216-841-11 METAL CHIP 47K 5% 1/16W
R206 1-216-833-11 METAL CHIP 10K 5% 1/16W
R207 1-216-833-11 METAL CHIP 10K 5% 1/16W
R208 1-216-833-11 METAL CHIP 10K 5% 1/16W
R209 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R211 1-216-833-11 METAL CHIP 10K 5% 1/16W
R212 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R213 1-216-797-11 METAL CHIP 10 5% 1/16W
R400 1-218-446-11 METAL CHIP 1 5% 1/10W
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R402 1-216-797-11 METAL CHIP 10 5% 1/16W
R403 1-216-805-11 METAL CHIP 47 5% 1/16W
R404 1-216-833-11 METAL CHIP 10K 5% 1/16W
R405 1-216-797-11 METAL CHIP 10 5% 1/16W
R406 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R407 1-216-841-11 METAL CHIP 47K 5% 1/16W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R409 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R410 1-216-833-11 METAL CHIP 10K 5% 1/16W
R411 1-216-841-11 METAL CHIP 47K 5% 1/16W
R412 1-216-833-11 METAL CHIP 10K 5% 1/16W
R413 1-216-857-11 METAL CHIP 1M 5% 1/16W
R414 1-216-803-11 METAL CHIP 33 5% 1/16W
R415 1-216-841-11 METAL CHIP 47K 5% 1/16W
R416 1-216-821-11 METAL CHIP 1K 5% 1/16W
R417 1-218-725-11 RES-CHIP 24K 5% 1/10W
R418 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R422 1-216-833-11 METAL CHIP 10K 5% 1/16W
R423 1-216-837-11 METAL CHIP 22K 5% 1/16W
R424 1-216-841-11 METAL CHIP 47K 5% 1/16W
R425 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R426 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R428 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VARIABLE RESISTOR >
RV101 1-241-766-11 RES, ADJ, CARBON 33K
RV201 1-241-766-11 RES, ADJ, CARBON 33K
< TRANSFORMER >
T101 1-419-080-21 COIL
T201 1-419-080-21 COIL
T401 1-433-372-31 TRANSFORMER, BIAS OSCILLATION
< THERMISTOR >
TH1 1-537-771-21 TERMINAL BOARD, GROUND
TH2 1-537-771-21 TERMINAL BOARD, GROUND
TH3 1-537-771-21 TERMINAL BOARD, GROUND
*************************************************************
1-684-509-12 VIDEO BOARD
***********
< CONNECTOR >
CN609 1-779-551-21 CONNECTOR,FFC(LIF(NON-ZIF))14P
< FERRITE BEAD >
FB671 1-469-144-21 FERRITE 0uH
FB672 1-469-144-21 FERRITE 0uH
FB674 1-469-144-21 FERRITE 0uH
< JACK >
J600 1-537-943-11 TERMINAL, S (S-VIDEO OUT)
J601 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
*************************************************************
MISCELLANEOUS
**************
3 1-824-198-11 WIRE (FLAT TYPE) (14 CORE)
60 1-824-195-11 WIRE (FLAT TYPE) (19 CORE)
110 1-796-456-11 DECK, MECHANICAL
113 1-824-192-11 WIRE (FLAT TYPE) (8 CORE)
154 1-824-194-11 WIRE (FLAT TYPE) (25 CORE)
155 1-824-193-11 WIRE (FLAT TYPE) (25 CORE)
158 1-824-201-11 WIRE (FLAT TYPE) (5 CORE)
159 1-824-200-11 WIRE (FLAT TYPE) (27 CORE)
