131
HCD-M700
160 1-824-199-11 WIRE (FLAT TYPE) (17 CORE)
161 1-824-196-11 WIRE (FLAT TYPE) (27 CORE) (HK)
161 1-824-593-11 WIRE (FLAT TYPE) (27 CORE) (AEP,UK)
163 1-773-048-11 WIRE (FLAT TYPE) (17 CORE)
201 1-824-197-11 WIRE (FLAT TYPE) (10 CORE)
202 1-824-202-11 WIRE (FLAT TYPE) (9 CORE)
203 1-824-203-11 WIRE (FLAT TYPE) (25 CORE)
0206 1-777-071-21 CORD, POWER
0418 8-820-144-06 OPTICAL PICK-UP (CD) KHM-240AAA (TYPE A)
0418 A-6062-709-A OPTICAL PICK-UP (CD) KHM-270AAA (TYPE B)
419 1-823-072-11 CABLE, FLEXIBLE FLAT 26P
759 1-678-514-11 PWB, FLEXIBLE
0760 A-467-254-1A OPTICAL PICK-UP BLOCK (MD) KMS-260E
FAN101 1-763-682-31 FAN, DC
HR901 1-500-670-22 HEAD, OVER LIGHT
M701 A-4735-757-A MOTOR ASSY, SPINDLE
M702 A-4735-076-A MOTOR ASSY, SLED
M703 A-4735-074-A MOTOR ASSY, LOADING
M901 A-4735-337-A MOTOR (LD) ASSY (LOADING)
S102 1-771-957-11 SWITCH, PUSH (2 KEY)
Ref. No. Part No. Description Remarks
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.1 2003.09
