HCD-SLK10D/SLK20D
63
Pin No. Pin Name I/O Description
1 USBA_ID I Not used
2 USBA_VBUS I VBUS (for USB connector) detection signal input terminal
3 USB VDD3.3 - Power supply terminal (+3.3V)
4 USBA D+ I/O Two-way USB data (+) bus with the USB connector
5 USBA D– I/O Two-way USB data (–) bus with the USB connector
6 USBA VSS3.3 - Ground terminal
7 USBA txrtune I Reference voltage input terminal
8 USBA VSS3.3 - Ground terminal
9 USBA VDD3.3 - Power supply terminal (+3.3V)
10 USBB_ID I Not used
11 USBB_VBUS - Not used
12 USBB VDD3.3 - Power supply terminal (+3.3V)
13 USBB D+ - Not used
14 USBB D– - Not used
15 USBB VSS - Ground terminal
16 USBB txrtune I Reference voltage input terminal
17 USBB VSS3.3C - Ground terminal
18 USBB VDD3.3 - Power supply terminal (+3.3V)
19 PLL VDD3.3 - Power supply terminal (+3.3V)
20 PLL VSS - Ground terminal
21 to 23 656D0 to 656D2 I Digital video data input from the video D/A converter
24 VDD3.3 - Power supply terminal (+3.3V)
25 to 27 656D3 to 656D5 I Digital video data input from the video D/A converter
28 VDD1.2 - Power supply terminal (+1.2V)
29, 30 656D6, 656D7 I Digital video data input from the video D/A converter
31 DVSS - Ground terminal
32 iPod DET - Not used
33 iPod Acc Power - Not used
34
Card Vcc
OverCurrent DET
I Card power over current detection signal input terminal
35 NC - Not used
36 SPI CS O Chip select signal output to the fl ash ROM
37 SPI HOLD O Hold signal output terminal Not used
38 SPI C/M1 D0 I/O
Serial data transfer clock signal output to the fl ash ROM
Two-way data bus with the SD-RAM
39 SPI D/M1 D1 I/O
Serial data output to the fl ash ROM
Two-way data bus with the SD-RAM
40 SPI Q/M1 D2 I/O
Serial data input from the fl ash ROM
Two-way data bus with the SD-RAM
41 SPI WP/M1 D3 I/O
Write protect signal output terminal Not used
Two-way data bus with the SD-RAM
42 VDD3.3 - Power supply terminal (+3.3V)
43, 44 M1 D4, M1 D5 I/O Two-way data bus with the SD-RAM
45 DVSS - Ground terminal
46, 47 M1 D6, M1 D7 I/O Two-way data bus with the SD-RAM
48 M1DQM0 O Data mask signal output to the SD-RAM
49 to 53 M1 D15 to M1 D11 I/O Two-way data bus with the SD-RAM
54 VDD3.3 - Power supply terminal (+3.3V)
55 to 57 M1 D10 to M1 D8 I/O Two-way data bus with the SD-RAM
58 M1DQM1 O Data mask signal output to the SD-RAM
59 DVSS - Ground terminal
60 M1 CLKO O Clock signal output to the SD-RAM
61 M1 CKE O Clock enable signal output terminal Not used
62 to 69
M1 A12, M1 A11,
M1 A9 to M1 A4
O Address signal output to the SD-RAM
70 VDD3.3 - Power supply terminal (+3.3V)
71 M1 WE n O Write enable signal output to the SD-RAM
72 M1 CAS n O Column address signal output to the SD-RAM
73 M1 RAS n O Row address signal output to the SD-RAM
DISPLAY BOARD IC401 AML6226D (AUDIO DSP, DISPLAY CONTROLLER)
