HCD-SLK10D/SLK20D
64
Pin No. Pin Name I/O Description
74 VDD1.2 - Power supply terminal (+3.3V)
75 M1 SCS0 n O Chip select signal output to the SD-RAM
76, 77 M1 BA0 n, M1 BA1 n O Bank address signal output to the SD-RAM
78 DVSS - Ground terminal
79 to 83
M1 A10,
M1 A3 to M1 A0
O Address signal output to the SD-RAM
84 LCD PWM180 O Not used
85 LCD PWM O Power control signal output terminal for liquid crystal display module
86 VDD3.3 - Power supply terminal (+3.3V)
87 LED PWM O Power control signal output terminal for liquid crystal display module back light LED
88 LED PWM180 O Not used
89 Remote Input I Not used
90
LED BackLightIC
Cont
O Not used
91 VGH10VCTL O VGH power on/off control signal output terminal “H”: power on
92 IPOD USB SEL - Not used
93 TADC AV3.3 - Power supply terminal (+3.3V)
94 to 105
TADC CH11 to
TADC CH0
I/O Not used
106 TADC CAP+ I/O Not used
107 TADC CAP– I/O Not used
108 TADC AGND - Ground terminal
109 LED CS0 I Feedback voltage input terminal for liquid crystal display back light LED power
110 LED CS1 I Over current protection signal input terminal for liquid crystal display back light LED power
111 RTC GPO O Not used
112 RTC VBAT I Not used
113 RTC XOUT O Not used
114 RTC XIN I Not used
115 RTC PDAC AGND - Ground terminal
116 REF12 VX O Not used
117 VREF12 FB I Not used
118, 119
VGHL CS0,
VGHL CS1
I Feedback voltage input terminal for VGL and VGH power
120 AOUT SPRC I Not used
121 AOUT SPR O Not used
122 AOUT HPR O Not used
123 AOUT HPRC I Not used
124 AOUT AVSS3.3 - Ground terminal
125 AOUT REFN I Not used
126 AOUT VCM O Not used
127 AOUT REFP I Not used
128 AOUT AVDD3.3 - Power supply terminal (+3.3V)
129 AOUT HPLC I Not used
130 AOUT HPL O Not used
131 AOUT SPL O Not used
132 AOUT SPLC I Not used
133 NC - Not used
134 VDD1.2 - Power supply terminal (+1.2V)
135 VDD3.3 - Power supply terminal (+3.3V)
136 to
139
LCD R0 to LCD R3 O RGB (red) signal output to the liquid crystal display module
140 DVSS - Ground terminal
141 to
144
LCD R4 to LCD R7 O RGB (red) signal output to the liquid crystal display module
145 to
149
LCD G0 to LCD G4 O RGB (green) signal output to the liquid crystal display module
150 VDD3.3 - Power supply terminal (+3.3V)
151 to
153
LCD G5 to LCD G7 O RGB (green) signal output to the liquid crystal display module
154 DVSS - Ground terminal
