HCD-SLK10D/SLK20D
65
Pin No. Pin Name I/O Description
155 to
162
LCD B0 to LCD B7 O RGB (blue) signal output to the liquid crystal display module
163 VDD1.2 - Power supply terminal (+1.2V)
164 VDD3.3 - Power supply terminal (+3.3V)
165 LCD SCL(SPI) - Not used
166 LCD DCLK O Data clock signal output to the liquid crystal display module
167 LCD HSYNC - Not used
166 LCD DE O Data enable signal output to the liquid crystal display module
169 LCD VSYNC - Not used
170 LCD CS(SPI) - Not used
171 LCD SDA(SPI) - Not used
172 DVSS - Ground terminal
173 LCD GBR O GBR signal output to the liquid crystal display module
174 iPod LINE MUTE O Not used
175 SD/MS INS I SD memory card and memory stick insert detection signal input terminal
176 SD WP I SD memory card write protect detection signal input terminal
177 SD CARD DET I SD memory card detection signal input terminal
178 DAC SMUTE O Muting on/off control signal output to the audio D/A converter “H”: muting on
179 VDD3.3 - Power supply terminal (+3.3V)
180 SD CMD/MS BS O
Command signal (for SD memory card) and bus state signal (for memory stick) output
terminal
181 SD/MS CLK O Serial data transfer clock signal (for SD memory card and memory stick) output terminal
182 iPod CP RESET - Not used
183, 184
SD/MS DAT3,
SD/MS DAT2
I/O Two-way data (for SD memory card and memory stick) bus terminal
185 VDD1.2 - Power supply terminal (+1.2V)
186, 187
SD/MS DAT1,
SD/MS DAT0
I/O Two-way data (for SD memory card and memory stick) bus terminal
188 SELB O Video signal selection signal output terminal
189 DVSS - Ground terminal
190 SELA O Video signal selection signal output terminal
191 Video AMP A MUTE O
Muting on/off control signal (for DVD VIDEO OUT jack) output to the video amplifi er
“L”: muting on
192 Video AMP B MUTE O
Muting on/off control signal (for liquid crystal display module) output to the video amplifi er
“L”: muting on
193 Video Dec RESET O Reset signal output to the video A/D converter “L”: reset
194 Video Dec AVID I Active video indicator signal input from the video A/D converter
195
Video Dec
INTREQ/GPCL
I Interrupt request signal input from the video A/D converter
196 Video Dec PDN O Power down signal output to the video A/D converter “L”: power down
197 AML BUSY O Busy signal output to the system controller
198 VDD3.3 - Power supply terminal (+3.3V)
199 Video Dec PCLK I Pixel clock signal input from the video A/D converter
200 Video Dec VSYNC I Vertical sync signal input from the video A/D converter
201 Video Dec HSYNC I Horizontal sync signal input from the video A/D converter
202 Video Dec AVID I Field indicator and color PLL information signal input from the video A/D converter
203 UART Rx I Serial data input from the system controller
204 UART Tx O Serial data output to the system controller
205 I2C SDA I/O Two-way I2C data bus with the video A/D converter
206 I2C SCK O I2C clock signal output to the video A/D converter
207 VDD3.3 - Power supply terminal (+3.3V)
208 VSS3.3 - Ground terminal
209 OSCIN I System clock input terminal (24 MHz)
210 OSCOUT O System clock output terminal (24 MHz)
211 MCLK O Master clock signal output to the audio A/D converter
212 BCK O Bit clock signal output to the audio A/D converter
213 LRCK O L/R sampling clock signal output to the audio A/D converter
214 MDATA O Digital audio data output to the audio A/D converter
215 CARD VCC ENABLE O
Power on/off control signal output terminal for SD memory card and memory stick
“H”: power on
216 RESET I Reset signal input from the system controller “L”: reset
To Next Page
