HCD-SLK10D/SLK20D
67
Pin No. Pin Name I/O Description
59 STBY-LED O
LED drive signal output terminal for ON/STANDBY indicator
“L”: red LED on (STANDBY), “H”: green LED on (ON)
60 P.CONT O Power on/off control signal output to the switching regulator “H”: power on
61 FAN-CONTROL O Fan motor drive signal output terminal “H”: motor on
62 VCC - Power supply terminal (+3.3V)
63 PROTECT FAN I Protect signal input from the fan motor
64 VSS - Ground terminal
65 NO USE - Not used
66 USB POWER O Power on/off control signal output terminal for USB section “H”: power on
67 MTK POWER O Power on/off control signal output terminal for DVD section “H”: power on
68 POWER-KEY I Power key input terminal
69 ST_CE O Chip enable signal output to the tuner (FM/AM)
70 ST_DOUT O Serial data output to the tuner (FM/AM)
71 ST_CLK O Serial data transfer clock signal output to the tuner (FM/AM)
72 ST_DIN l Serial data input from the tuner (FM/AM)
73 /SD I Shut down signal input from the digital power amplifi er “L”: shut down
74 ST_TUNED I Tuning detection signal input from the tuner (FM/AM) “L”: tuned
75 TP INT I Interrupt signal input from the TOUCH SENSOR board
76 TP RESET O Reset signal output to the TOUCH SENSOR board “L”: reset
77 DSP-DATA I/O Two-way data bus with the digital audio processor
78 DSP-CLK O Serial data transfer clock signal output to the digital audio processor
79 DSP-VAILD I Valid signal input from the digital audio processor
80 DSP-MUTE O Muting on/off control signal output to the digital audio processor “L”: muting on
81 DSP-RESET O Reset signal output to the digital audio processor “L”: reset
82 DVD 3.3V MONITOR I Power (DVD +3.3V) monitor terminal
83 NO USE - Not used
84, 85
AD-KEY-1,
AD-KEY-0
I Top and front panel key input terminal (A/D input)
86 RDS-DATA I RDS serial data input from the tuner (FM/AM)
87 NO USE - Not used
88 Vbus+5V_SW O Power on/off control signal output terminal for USB section “H”: power on
89 USB_D+_D-_SW O USB signal selection signal output terminal
90 USB_D+_D-_OE O Output enable signal output to the USB select IC
91 NO USE O Not used
92 VACS I VACS signal input from the digital audio processor
93, 94 NO USE - Not used
95 DEST-IN I Destination setting terminal
96 AVSS - Ground terminal
97 MODEL I Model setting terminal
98 VREF I Reference voltage (+3.3V) input terminal
99 AVCC - Power supply terminal (+3.3V)
100
NO USE
(AD-SWITCH)
O Power on/off control signal output terminal Not used
