HCD-SLK10D/SLK20D
8
TOUCH PANEL BOARD SERVICE POSITION
– Rear bottom view –
insulating sheet
Note:
Do not insert
the wire (flat type)
in the same amount of connector by mistake.
Refer to “2-21. HOW TO BEND WIRE (FLAT TYPE)” (page 24) and “5-1.
FLAME PRINTED WIRING BOARDS”
(page 31) for details.
FAN motor
MAIN board
DISPLAY board
DMB19 board
LOGO board
TOUCH PANEL board
LCD module
JACK board
switching regulator
DVD mechanism deck
(CDM86S-DVBU101)
insulating sheet
insulating sheet
