Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SLK10D/SLK20D
8585
CN4601 1-784-857-51 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< DIODE >
D001 6-500-848-01 DIODE MC2840-T112-1
D002 6-500-848-01 DIODE MC2840-T112-1
D003 6-500-848-01 DIODE MC2840-T112-1
D004 6-500-848-01 DIODE MC2840-T112-1
D005 6-500-848-01 DIODE MC2840-T112-1
D006 6-500-848-01 DIODE MC2840-T112-1
< EARTH TERMINAL >
ET001 1-780-482-11 EARTH TERMINAL
ET002 1-780-482-11 EARTH TERMINAL
ET003 1-780-482-11 EARTH TERMINAL
ET004 1-780-482-11 EARTH TERMINAL
< FERRITE BEAD >
FB106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB109 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB112 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB113 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB603 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB604 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB606 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB607 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB608 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB609 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB613 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1264 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1265 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1266 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1267 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1268 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1290 1-469-670-21 FERRITE, EMI (SMD) (2012)
< FILTER >
FL105 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL602 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL603 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL604 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 6-714-820-01 IC CXD9970R (LE)
IC102 (Not supplied) IC MX25L3206EM2I-12G-TR
IC103 (Not supplied) IC S-24CS16A0I-J8T1G
IC104 6-714-642-01 IC EM638165 TSA-6G
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC111 6-706-838-01 IC MM1661JHBE
IC201 6-704-524-01 IC FAN8036L
IC4602 6-704-819-01 IC CS4335-KSZR
< TRANSISTOR >
Q101 6-550-008-01 FET UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-029-06 TRANSISTOR DTC124EUA-T106
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-864-11 SHORT CHIP 0
R103 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-809-11 METAL CHIP 100 5% 1/10W
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R125 1-216-833-11 METAL CHIP 10K 5% 1/10W
R133 1-216-864-11 SHORT CHIP 0
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R151 1-216-833-11 METAL CHIP 10K 5% 1/10W
R154 1-216-295-91 SHORT CHIP 0
R155 1-216-295-91 SHORT CHIP 0
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R191 1-216-821-11 METAL CHIP 1K 5% 1/10W
R192 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R193 1-216-821-11 METAL CHIP 1K 5% 1/10W
R204 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R208 1-216-839-11 METAL CHIP 33K 5% 1/10W
R209 1-216-839-11 METAL CHIP 33K 5% 1/10W
R210 1-216-841-11 METAL CHIP 47K 5% 1/10W
R212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R213 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R214 1-216-835-11 METAL CHIP 15K 5% 1/10W
R215 1-216-834-11 METAL CHIP 12K 5% 1/10W
R216 1-216-834-11 METAL CHIP 12K 5% 1/10W
R219 1-216-838-11 METAL CHIP 27K 5% 1/10W
R220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R221 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R223 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R225 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R226 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R227 1-216-864-11 SHORT CHIP 0
R228 1-216-864-11 SHORT CHIP 0
R230 1-218-893-11 METAL CHIP 82K 0.5% 1/10W
R231 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R232 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R233 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R236 1-216-809-11 METAL CHIP 100 5% 1/10W
R237 1-216-821-11 METAL CHIP 1K 5% 1/10W
R239 1-216-821-11 METAL CHIP 1K 5% 1/10W
DMB19
Note: IC102 and IC103 on the DMB19 board cannot exchange with single.
When these parts are damaged, exchange the complete mounted board.
