Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SLK10D/SLK20D
86
R246 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R247 1-216-821-11 METAL CHIP 1K 5% 1/10W
R254 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R255 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R256 1-216-833-11 METAL CHIP 10K 5% 1/10W
R521 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1029 1-216-864-11 SHORT CHIP 0
R1032 1-216-864-11 SHORT CHIP 0
R1101 1-218-841-11 METAL CHIP 560 0.5% 1/10W
R1110 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R1114 1-216-801-11 METAL CHIP 22 5% 1/10W
R1121 1-216-864-11 SHORT CHIP 0
R1123 1-216-864-11 SHORT CHIP 0
R1129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1150 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1151 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1152 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1168 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R1177 1-216-864-11 SHORT CHIP 0
R1178 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1184 1-216-809-11 METAL CHIP 100 5% 1/10W
R1191 1-216-864-11 SHORT CHIP 0
R1192 1-216-864-11 SHORT CHIP 0
R1193 1-216-864-11 SHORT CHIP 0
R1194 1-216-864-11 SHORT CHIP 0
R1249 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1252 1-216-295-91 SHORT CHIP 0
R1253 1-216-295-91 SHORT CHIP 0
R1255 1-216-295-91 SHORT CHIP 0
R1257 1-216-864-11 SHORT CHIP 0
R1261 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1262 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1263 1-216-864-11 SHORT CHIP 0
R1269 1-216-809-11 METAL CHIP 100 5% 1/10W
R1270 1-216-864-11 SHORT CHIP 0
R1271 1-216-864-11 SHORT CHIP 0
R1276 1-216-864-11 SHORT CHIP 0
R1277 1-216-809-11 METAL CHIP 100 5% 1/10W
R1278 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1279 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1280 1-216-864-11 SHORT CHIP 0
R1281 1-216-809-11 METAL CHIP 100 5% 1/10W
R1282 1-216-801-11 METAL CHIP 22 5% 1/10W
R1283 1-216-809-11 METAL CHIP 100 5% 1/10W
R2502 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2505 1-216-864-11 SHORT CHIP 0
R2506 1-216-857-11 METAL CHIP 1M 5% 1/10W
R2507 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4833 1-216-817-11 METAL CHIP 470 5% 1/10W
R4834 1-216-817-11 METAL CHIP 470 5% 1/10W
R4835 1-216-295-91 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB105 1-242-963-21 RES, NETWORK 33 (1005X4)
RB106 1-242-963-21 RES, NETWORK 33 (1005X4)
RB107 1-242-963-21 RES, NETWORK 33 (1005X4)
RB108 1-242-963-21 RES, NETWORK 33 (1005X4)
RB111 1-242-963-21 RES, NETWORK 33 (1005X4)
RB112 1-242-963-21 RES, NETWORK 33 (1005X4)
RB113 1-242-963-21 RES, NETWORK 33 (1005X4)
RB114 1-242-963-21 RES, NETWORK 33 (1005X4)
RB115 1-242-963-21 RES, NETWORK 33 (1005X4)
< VIBRATOR >
X101 1-814-380-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
HP BOARD
********
< CAPACITOR >
C241 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C244 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN241 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
< DIODE >
D244 6-500-848-01 DIODE MC2840-T112-1
< IC >
IC242 6-600-780-01 IC PNA4823M05S0
< JACK >
J241 1-794-702-11 JACK, HEADPHONE (
i )
< RESISTOR >
R241 1-216-809-11 METAL CHIP 100 5% 1/10W
R242 1-216-821-11 METAL CHIP 1K 5% 1/10W
R243 1-216-864-11 SHORT CHIP 0
R244 1-216-864-11 SHORT CHIP 0
************************************************************
JACK BOARD
**********
< CAPACITOR >
C701 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C702 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C704 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C705 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C706 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C707 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-126-518-11 ELECT 470uF 20% 4V
C718 1-126-518-11 ELECT 470uF 20% 4V
< CONNECTOR >
CN705 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< JACK >
J701 1-815-043-11 JACK, PIN 2P
(VIDEO/SAT VIDEO IN, DVD VIDEO OUT)
J704 1-778-940-11 JACK 2P (VIDEO/SAT AUDIO IN)
< JUMPER RESISTOR >
JR701 1-216-864-11 SHORT CHIP 0
JR702 1-216-864-11 SHORT CHIP 0
HPDMB19 JACK
