Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SLK10D/SLK20D
8787
< RESISTOR >
R701 1-216-821-11 METAL CHIP 1K 5% 1/10W
R702 1-216-821-11 METAL CHIP 1K 5% 1/10W
R703 1-216-845-11 METAL CHIP 100K 5% 1/10W
R704 1-216-845-11 METAL CHIP 100K 5% 1/10W
R707 1-216-295-91 SHORT CHIP 0
R711 1-216-295-91 SHORT CHIP 0
************************************************************
KEY_LEFT BOARD
**************
< CAPACITOR >
C262 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C263 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
CN261 1-779-275-11 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN262 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< DIODE >
D261 6-500-848-01 DIODE MC2840-T112-1
D262 6-502-843-01 LED CL-165HR/HG5-D-T (ON/STANDBY)
D270 6-502-961-01 DIODE DA2J10100L
< TRANSISTOR >
Q261 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R261 1-216-813-11 METAL CHIP 220 5% 1/10W
R262 1-216-818-11 METAL CHIP 560 5% 1/10W
R263 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S261 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE) (
\/1 )
************************************************************
KEY_RIGHT BOARD
***************
< CONNECTOR >
CN263 1-784-365-51 CONNECTOR, FFC/FPC 5P
< RESISTOR >
R265 1-216-821-11 METAL CHIP 1K 5% 1/10W
R268 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R269 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S263 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE) (VOL –)
S265 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE) (VOL +)
S266 1-572-595-11 SWITCH, TACTILE (REFLOW TYPE) (
Z )
************************************************************
LOGO BOARD
**********
< LED >
* D1000 6-502-466-01 LED CL-270S-WS-SD-TS (SONY LOGO)
* D1001 6-502-466-01 LED CL-270S-WS-SD-TS (SONY LOGO)
< TRANSISTOR >
Q1000 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R1000 1-216-813-11 METAL CHIP 220 5% 1/10W
************************************************************
A-1821-478-A MAIN BOARD, COMPLETE (E2)
A-1821-512-A MAIN BOARD, COMPLETE (E51)
A-1821-521-A MAIN BOARD, COMPLETE (MX)
A-1821-539-A MAIN BOARD, COMPLETE (IND)
A-1821-800-A MAIN BOARD, COMPLETE (SP, TH)
A-1821-807-A MAIN BOARD, COMPLETE (CH)
A-1822-470-A MAIN BOARD, COMPLETE (BR)
A-1831-525-A MAIN BOARD, COMPLETE (EA)
********************
< CAPACITOR >
C110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C111 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C112 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C114 1-119-941-91 ELECT 470uF 20% 6.3V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C149 1-126-157-11 ELECT 10uF 20% 16V
C150 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C162 1-126-382-11 ELECT 100uF 20% 16V
C164 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C196 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C197 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C199 1-126-382-11 ELECT 100uF 20% 16V
C200 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C201 1-126-157-11 ELECT 10uF 20% 16V
C202 1-119-941-91 ELECT 470uF 20% 6.3V
C203 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C208 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C301 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
* C306 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C307 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C311 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C314 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C315 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C316 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C317 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(E2, E51)
C317 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
(EA, MX, BR, SP, TH, IND)
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V (CH)
C318 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(E2, E51)
C318 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
(EA, MX, BR, SP, TH, IND)
C318 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V (CH)
C326 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C327 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C328 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C329 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C330 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C338 1-115-872-11 ELECT 2.2uF 20% 50V
C339 1-115-872-11 ELECT 2.2uF 20% 50V
C340 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C341 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
JACK KEY_RIGHTKEY_LEFT MAINLOGO
