HCD-VX888
6-13. SCHEMATIC DIAGRAM – VIDEO SWITCH Board –
6-15. PRINTED WIRING BOARD – VIDEO SWITCH Board –• See page 27 for Circuit Boards Location.
1-680-892-
11
(11)
VIDEO OUT
J401
AUDIO OUT
J402
VIDEO SWITCH BOARD
1
4
5
8
C
PANEL BOARD
NO606
R
VIDEO BOARD
E
B
L R
Q
MAIN BORD
NO403
B
C
A
1 2 3 4
(Page 39)
(Page 47)
(Page 34)
D781 B-2
D782 B-2
IC401 B-3
IC781 B-1
Q401 B-4
• Semiconductor
Location
Ref. No. Location
6-14. PRINTED WIRING BOARDS – HEAD (A)/(B) Board –
• See page 27 for Circuit Boards Location. • See page 32 for Schematic Diagram of Head Board.
