Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
83
HCD-VX888
< CONNECTOR >
CN403 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN607 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
* CN781 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D781 8-719-988-61 DIODE 1SS355TE-17
D782 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC401 8-759-525-25 IC BU4052BCF-E2
IC781 8-759-295-90 IC NJM2244M-TE2
< JACK >
J401 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
J402 1-770-612-12 JACK, PIN 2P (AUDIO OUT)
< TRANSISTOR >
Q401 8-729-113-13 TRANSISTOR FA1A4M-T1L33
< RESISTOR >
R401 1-216-845-11 METAL CHIP 100K 5% 1/16W
R402 1-216-845-11 METAL CHIP 100K 5% 1/16W
R403 1-216-845-11 METAL CHIP 100K 5% 1/16W
R404 1-216-821-11 METAL CHIP 1K 5% 1/16W
R405 1-216-845-11 METAL CHIP 100K 5% 1/16W
R451 1-216-845-11 METAL CHIP 100K 5% 1/16W
R452 1-216-845-11 METAL CHIP 100K 5% 1/16W
R453 1-216-845-11 METAL CHIP 100K 5% 1/16W
R454 1-216-821-11 METAL CHIP 1K 5% 1/16W
R455 1-216-845-11 METAL CHIP 100K 5% 1/16W
R481 1-216-833-11 METAL CHIP 10K 5% 1/16W
R782 1-216-845-11 METAL CHIP 100K 5% 1/16W
R783 1-218-285-11 RES-CHIP 75 5% 1/16W
**************************************************************
MISCELLANEOUS
**************
013 1-757-852-11 CORD, CONNCTION
15 1-690-589-31 WIRE (FLAT TYPE) (13 CORE) (EXCEPT E91)
15 1-769-987-11 WIRE (FLAT TYPE) (13 CORE) (E91)
16 1-757-421-11 WIRE (FLAT TYPE) (25 CORE)
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
0108 1-777-071-51 CORD, POWER
509 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
535 1-541-632-12 MOTOR, CD (TURN)
602 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0603 A-4735-189-A BU-30 (61) ASSY
HP901 A-2004-771-A BASE (A) ASSY, HEAD
HRP901 A-2004-772-A BASE (B) ASSY, HEAD
M721 A-4672-826-A MOTOR ASSY
M901 X-3378-241-1 MOTOR ASSY (CAPSTAN)
M961 1-763-072-11 FAN, D.C.
PM901 1-454-887-32 SOLENOID, PLUNGER
PM901 1-454-887-32 SOLENOID, PLUNGER
0T910 1-437-356-11 POWER TRANSFOMER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-103-19 + PTPWH (2X5)
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#4 7-685-881-09 SCREW +BVTT 4X8 (S)
#5 7-627-853-28 SCREW, PRECISION +P 2X3 TYPE3
#6 7-628-254-05 SCREW +PS 2.6X5
#7 7-623-921-01 RING, RETAINING, CAPSTAN
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-569-008-21 ADAPTOR, CONVERSION 2P (EXCEPT E91)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
VIDEO SWITCH
Ver 1.1 2001.07
