Sony hcd-vx888 - CD Mechanism Deck; Front Panel Section

9
HCD-VX888
2-4. CD MECHANISM DECK (CDM58E-30BD61A)
2-5. FRONT PANEL SECTION
6 screw (+BVTP 3 × 10)
5 screw (+BVTP 3 × 10)
1 wire (flat type)
(15 core)
(CN201)
6 screw
(+BVTP 3
× 10 )
2 connector
(
CN202)
3 connector
(
CN403)
4 connector
(
CN781)
7 CD mechanism deck
(CDM58E-30BD61A)
9
6
two screws
(+BVTP 3
× 10 )
7 screws (+BVTP 3 × 10 )
8 Screws
(+BVTP 3
× 10)
5 screw
(+BVTP 3
× 10)
2 wire (flat type)
(17 core)
(CN304)
3 connector ( CN1)
4 connector ( CN2)
0 front panel section
1 connector ( CN607)
