67
HCD-VX888
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ADDRESS SENSOR
BD
1-675-911-14 ADDRESS SENSOR BOARD
**********************
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< IC >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN)
**************************************************************
A-4725-561-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C102 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C103 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C110 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C111 1-126-607-11 ELECT CHIP 47uF 20% 4V
C112 1-126-607-11 ELECT CHIP 47uF 20% 4V
C113 1-126-209-11 ELECT CHIP 100uF 20% 4V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C117 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C118 1-164-346-11 CERAMIC CHIP 1uF 16V
C119 1-164-346-11 CERAMIC CHIP 1uF 16V
C120 1-126-607-11 ELECT CHIP 47uF 20% 4V
C151 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C153 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C163 1-117-681-11 ELECT CHIP 100uF 20% 16V
C164 1-163-038-00 CERAMIC CHIP 0.1uF 25V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
C165 1-124-779-00 ELECT CHIP 10uF 20% 16V
C166 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C182 1-128-995-21 ELECT CHIP 100uF 20% 10V
C201 1-126-246-11 ELECT CHIP 220uF 20% 4V
C202 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C205 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C212 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C221 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C222 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C224 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C226 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C227 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C228 1-164-346-11 CERAMIC CHIP 1uF 16V
C229 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C231 1-128-995-21 ELECT CHIP 100uF 20% 10V
C234 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C235 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C236 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
< CONNECTOR >
CN101 1-784-875-21 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
CN102 1-794-424-11 CONNECTOR, FCC/FPC 16P
< DIODE >
D101 8-719-056-77 DIODE UDZ-TE-17-3.9B
< FERRITE BEAD >
FB101 1-500-445-21 FERRITE 0uH
< IC >
IC101 8-752-408-73 IC CXD3068Q
IC102 8-759-713-70 IC AN41020A
IC103 8-752-089-74 IC CXA2581N-T4
IC106 8-759-834-29 IC MC74VHC1G04DFT1
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710A-RTX
Q103 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
• Abbreviation
E3 : 240 V AC Area in E model
E91 : 220 V AC Area in E model
EA : Saudi Arabia model
IA : Indonesia model
SP2/6: Malaysia, Singapore model
