Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
68
HCD-VX888
< RESISTOR >
R102 1-216-077-00 RES-CHIP 15K 5% 1/10W
R103 1-216-097-11 RES-CHIP 100K 5% 1/10W
R104 1-216-077-00 RES-CHIP 15K 5% 1/10W
R105 1-216-049-11 RES-CHIP 1K 5% 1/10W
R111 1-216-099-00 METAL CHIP 120K 5% 1/10W
R113 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R114 1-216-102-00 RES-CHIP 160K 5% 1/10W
R115 1-216-085-91 RES-CHIP 33K 5% 1/10W
R116 1-216-085-91 RES-CHIP 33K 5% 1/10W
R118 1-216-295-11 SHORT 0
R120 1-216-099-00 METAL CHIP 120K 5% 1/10W
R122 1-216-097-11 RES-CHIP 100K 5% 1/10W
R123 1-216-001-00 METAL CHIP 10 5% 1/10W
R124 1-216-797-11 METAL CHIP 10 5% 1/16W
R125 1-216-085-91 RES-CHIP 33K 5% 1/10W
R126 1-216-085-91 RES-CHIP 33K 5% 1/10W
R151 1-216-097-11 RES-CHIP 100K 5% 1/10W
R152 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R163 1-216-295-11 SHORT 0
R164 1-216-295-11 SHORT 0
R167 1-216-295-11 SHORT 0
R168 1-216-295-11 SHORT 0
R176 1-216-295-11 SHORT 0
R179 1-216-864-11 METAL CHIP 0 5% 1/16W
R201 1-216-085-91 RES-CHIP 33K 5% 1/10W
R202 1-216-073-91 RES-CHIP 10K 5% 1/10W
R203 1-216-097-11 RES-CHIP 100K 5% 1/10W
R204 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R205 1-216-049-11 RES-CHIP 1K 5% 1/10W
R206 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R207 1-216-121-11 RES-CHIP 1M 5% 1/10W
R212 1-216-033-00 METAL CHIP 220 5% 1/10W
R215 1-216-295-11 SHORT 0
R218 1-216-049-11 RES-CHIP 1K 5% 1/10W
R219 1-216-049-11 RES-CHIP 1K 5% 1/10W
R220 1-216-295-11 SHORT 0
R221 1-216-033-00 METAL CHIP 220 5% 1/10W
R222 1-216-033-00 METAL CHIP 220 5% 1/10W
R223 1-216-025-11 RES-CHIP 100 5% 1/10W
R224 1-216-033-00 METAL CHIP 220 5% 1/10W
R225 1-216-033-00 METAL CHIP 220 5% 1/10W
R226 1-216-025-11 RES-CHIP 100 5% 1/10W
R227 1-216-097-11 RES-CHIP 100K 5% 1/10W
R228 1-216-113-00 METAL CHIP 470K 5% 1/10W
R229 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R230 1-216-295-11 SHORT 0
R235 1-216-025-11 RES-CHIP 100 5% 1/10W
R236 1-216-025-11 RES-CHIP 100 5% 1/10W
R237 1-216-025-11 RES-CHIP 100 5% 1/10W
R239 1-216-035-00 METAL CHIP 270 5% 1/10W
R240 1-216-295-11 SHORT 0
< NETWORK RESISTOR >
RN201 1-233-576-11 RES, CHIP NETWORK 100
RN202 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR >
RV101 1-223-997-21 RES, CARBON ADJ VAR 47K
**************************************************************
1-680-263-11 CD-SW BOARD
************
< DIODE >
D791 8-719-057-97 LED SEL5923A-TP15 (DISC 1)
D792 8-719-057-97 LED SEL5923A-TP15 (DISC 2)
D793 8-719-057-97 LED SEL5923A-TP15 (DISC 3)
D794 8-719-071-44 LED SELS5223C-TP15 (?/1)
< TRANSISTOR >
Q791 8-729-900-80 TRANSISTOR BA1A4M-TP
Q792 8-729-900-80 TRANSISTOR BA1A4M-TP
Q793 8-729-900-80 TRANSISTOR BA1A4M-TP
Q794 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R791 1-249-419-11 CARBON 1.5K 5% 1/4W
R792 1-249-421-11 CARBON 2.2K 5% 1/4W
R793 1-249-422-11 CARBON 2.7K 5% 1/4W
R794 1-249-424-11 CARBON 3.9K 5% 1/4W
R795 1-249-426-11 CARBON 5.6K 5% 1/4W
R796 1-249-410-11 CARBON 270 5% 1/4W
R798 1-249-409-11 CARBON 220 5% 1/4W
R799 1-249-409-11 CARBON 220 5% 1/4W
R800 1-249-417-11 CARBON 1K 5% 1/4W
R801 1-249-409-11 CARBON 220 5% 1/4W
< SWITCH >
S791 1-771-410-21 SWITCH, TACTILE (Z OPEN/CLOSE) (CD)
S792 1-771-410-21 SWITCH, TACTILE (DISK SKIP/EX-CHANGE)
S793 1-771-410-21 SWITCH, TACTILE (DISC 3)
S794 1-771-410-21 SWITCH, TACTILE (DISC 2)
S795 1-771-410-21 SWITCH, TACTILE (DISC 1)
S796 1-771-410-21 SWITCH, TACTILE (?/1)
**************************************************************
1-675-912-14 DRIVER BOARD
*************
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR (LIGHT ANGLE) 10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-983-68 DIODE MTZJ-T-72-3.9A
< IC >
IC701 8-759-598-69 IC BA6956AN
BD CD-SW DRIVER
