HCD-VX888
7-5. BASE UNIT SECTION
(BU-30BD61A)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
601 A-4725-561-A BD BOARD, COMPLETE
602 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0603 A-4735-189-A BU-30 (61) ASSY
602
601
603
Ver 1.1 2001.07
