5050
HCD-VX888
• Waveforms
– BD Board –
1 IC101 t; (RFAC) (CD Play mode) 6 IC601 is (X OUT) (Stop mode)
1.3 Vp-p
– PANEL Board –
3.5 Vp-p
4 MHz
– MAIN Board –
2 IC501 qa (XC OUT) (Stop mode)
3.1 Vp-p
32.768 kHz
2 IC101 ra (TE) (CD Play mode)
Approx.
0.5 Vp-p
3 IC501 qd (X OUT) (Stop mode)
3.8 Vp-p
16 MHz
3 IC101 el (FE) (CD Play mode)
Approx.
0.4 Vp-p
1 IC51 ws (X OUT) (TUNER (FM))
4.3 Vp-p
4.5 MHz
4 T301 4 (DECK-B REC mode)
128 Vp-p
80 kHz
5 NO303 3 (L-REC), 6 (R-REC)
(DECK-B REC mode)
52 Vp-p
80 kHz
4 IC101 wh (MDP)
2.3 Vp-p
7.5 µs
– VIDEO Board –
1 IC502 qd (XOUT) qa J301 4 (YOUT)6 IC505 <z/,> (DA-LRCK)
2 IC505 ih (DA-XCLK) 7 IC505 <zzz> (DA-BCK)
3 IC505 od (VSYNC)
0 IC509 4 (MCKO)
9 IC509 wf (XT2)
8 IC509 w; (384FSO)
4 IC505 <z/z> (HSYNC)
4.6 Vp-p
10 MHz
3.6 Vp-p
17 MHz
3.5 Vp-p
20 ms
3.2 Vp-p
64 µs
5 IC505 <z/n> (VCK-IN)
5.4 Vp-p
37 nsec
4.5 Vp-p
22.7 µs
4.5 Vp-p
472 ns
2.0 Vp-p
37 ns
2.0 Vp-p
H
qs J301 (COUT)
H
2.0 Vp-p
qd CN301 2 (VIDEO OUT)
1.3 Vp-p
H
5.2 Vp-p
37 us
