HCD-VX888
Pin No. Pin Name I/O Description
84
STBY-RELAY O Standby relay on/off control signal output to the RY971 “H”: relay on
85
REAR-RELAY O Rear speaker relay on/off control signal output to the STA. AMP (TA-DX80) “H”: relay on
86 SURR-RELAY O
Surround speaker relay on/off control signal output terminal “H”: relay on Not used (open)
87 FRONT-RELAY O
Front speaker relay on/off control signal output to the RY801 “H”: relay on
88 PROTECT
I Speaker protect signal input terminal “L”: protect on
89
A-SHUT I Shut off detection signal input from the deck-A side reel pulse detector
90 B-SHUT I Shut off detection signal input from the deck-B side reel pulse detector
91
B-HALF I Detection input from the deck-B half detect switch “L”: cassette in, “H”: no cassette
92
MODEL-IN I Model select signal input terminal
93
SPEC-IN I Version select signal input terminal
94
FREQ-B O Frequency control signal output to the Booster AMP (TA-DX80)
95
FREQ-A O Frequency control signal output to the Booster AMP (TA-DX80)
96
AVSS — Ground terminal (for analog)
97 BOOSTER-SW
I Booster encoder signal input from the satellite AMP (TA-DX80)
98
VREF — Analog reference voltage terminal
99 AVCC —
Power supply terminal (+5V) (for analog)
100
AC CUT I AC power off detection signal input from the reset signal generator (IC502)
