Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
76
HCD-VX888
MAIN MAIN TRANS MOTOR PAD SWITCH
< TRANSFORMER >
T11 1-435-792-11 TRANSFORMER, DISCRIMINATOR
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1 1-694-555-22 TERMINAL BOARD (4P) (ANTENNA)
TM801 1-694-635-12 TERMINAL BOARD (4P) (SPEAKER)
< VIBRATOR >
X51 1-760-549-31 VIBRATOR, CRYSTAL (4.5MHz)
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
1-680-265-11 MAIN TRANS BOARD
*****************
1-533-217-11 HOLDER, FUSE
< CAPACITOR >
C941 1-128-553-11 ELECT 220uF 20% 63V
< CONNECTOR >
CN973 1-568-106-11 PIN, CONNECTOR 4P (EXCEPT E91)
CN973 1-564-321-00 PIN, CONNECTOR 2P (E91)
CN977 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0F971 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(EXCEPT E91)
0F974 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
0F975 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
0F976 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG)
(T8.0AL/250V)
0F977 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG)
(T8.0AL/250V)
< RESISTOR >
0R941 1-217-637-00 FUSIBLE 1 5% 1/4W F
0R944 1-217-641-00 FUSIBLE 4.7 5% 1/4W F
0R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
0R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W
< TRANSFORMER >
0T910 1-437-356-11 POWER TRANSFORMER
**************************************************************
1-675-910-14 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE)
**************************************************************
A-2007-995-A PAD SWITCH BOARD, COMPLETE (IA)
A-4476-103-A PAD SWITCH BOARD, COMPLETE
(E3, EA, SP2/6)
A-4725-802-A PAD SWITCH BOARD, COMPLETE (E91)
***************************
< CAPACITOR >
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-162-306-11 CERAMIC 0.01uF 30% 16V
< DIODE >
D751 8-719-063-93 LED SLR325VC-N-T32 (REC PAUSE/START)
D752 8-719-063-93 LED SLR325VC-N-T32 (ENTER)
< TRANSISTOR >
Q751 8-729-900-80 TRANSISTOR BA1A4M-TP
Q752 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R750 1-249-410-11 CARBON 270 5% 1/4W
R751 1-249-415-11 CARBON 680 5% 1/4W
R752 1-249-411-11 CARBON 330 5% 1/4W
R754 1-249-410-11 CARBON 270 5% 1/4W
R755 1-249-413-11 CARBON 470 5% 1/4W
R756 1-249-414-11 CARBON 560 5% 1/4W
R757 1-249-416-11 CARBON 820 5% 1/4W
R758 1-249-417-11 CARBON 1K 5% 1/4W
R759 1-249-418-11 CARBON 1.2K 5% 1/4W
R760 1-249-419-11 CARBON 1.5K 5% 1/4W
R761 1-249-421-11 CARBON 2.2K 5% 1/4W
R762 1-249-422-11 CARBON 2.7K 5% 1/4W
R763 1-249-424-11 CARBON 3.9K 5% 1/4W
R764 1-249-426-11 CARBON 5.6K 5% 1/4W
R765 1-249-428-11 CARBON 8.2K 5% 1/4W
R766 1-249-431-11 CARBON 15K 5% 1/4W
R767 1-249-434-11 CARBON 27K 5% 1/4W
R768 1-249-410-11 CARBON 270 5% 1/4W
R769 1-249-413-11 CARBON 470 5% 1/4W
R770 1-249-414-11 CARBON 560 5% 1/4W
R771 1-249-416-11 CARBON 820 5% 1/4W
R772 1-249-417-11 CARBON 1K 5% 1/4W
R773 1-249-418-11 CARBON 1.2K 5% 1/4W
R774 1-249-419-11 CARBON 1.5K 5% 1/4W
R775 1-249-421-11 CARBON 2.2K 5% 1/4W
R776 1-249-422-11 CARBON 2.7K 5% 1/4W
R777 1-249-424-11 CARBON 3.9K 5% 1/4W
R778 1-249-426-11 CARBON 5.6K 5% 1/4W
R779 1-249-428-11 CARBON 8.2K 5% 1/4W
R780 1-249-431-11 CARBON 15K 5% 1/4W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
