Sony HDC3500 - Page 45

45
<SWITCH ASSIGN1>
15 (U09)
*1
*1: See page 53 .
VF ASSIGN OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, INCOM1,
INCOM2, EXTENDER,
D.EXTENDER, 5600K, VF DETAIL,
SPIRIT LEVEL INDICATOR, FOCUS
ASSIST INDICATOR, PinP, VF
ASSIGN SW1, VF ASSIGN SW2,
RET1 SW TOGGLE, RET2 SW
TOGGLE, RET3 SW TOGGLE, VTR
S/S, TALLY R, TALLY G, TALLY Y,
FAN MAX, CURSOR ALL OFF,
FLAG, AWB, CALL, ZOOM(T),
ZOOM(W)
Displayed only when HDLA is attached.
Note
INCOM1 and INCOM2 are displayed on the UCJ
model only. ENG and PROD are displayed instead on
the CE model.
VF OUT SW VF OUT RGB
, FOCUS POSITION
METER
Displayed only when HDLA is attached.
(When set to FOCUS POSITION METER, VF OUT SW
(R/G/B) can be used to register/display marker
1/2/3.)
INSIDE RET1 OFF, RETURN1 SW
, RETURN2
SW, RETURN3 SW, INCOM1,
INCOM2, EXTENDER,
D.EXTENDER, 5600K, VF DETAIL,
SPIRIT LEVEL INDICATOR, FOCUS
ASSIST INDICATOR, PinP, VF
ASSIGN SW1, VF ASSIGN SW2,
RET1 SW TOGGLE, RET2 SW
TOGGLE, RET3 SW TOGGLE, VTR
S/S, TALLY R, TALLY G, TALLY Y,
FAN MAX, CURSOR ALL OFF,
FLAG, AWB, CALL, ZOOM(T),
ZOOM(W)
Assigns functions executed when you press the RET
1 button.
Note
INCOM1 and INCOM2 are displayed on the UCJ
model only. ENG and PROD are displayed instead on
the CE model.
INSIDE RET2 OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, INCOM1,
INCOM2, EXTENDER,
D.EXTENDER, 5600K, VF DETAIL,
SPIRIT LEVEL INDICATOR, FOCUS
ASSIST INDICATOR, PinP, VF
ASSIGN SW1, VF ASSIGN SW2,
RET1 SW TOGGLE, RET2 SW
TOGGLE, RET3 SW TOGGLE, VTR
S/S, TALLY R, TALLY G, TALLY Y,
FAN MAX, CURSOR ALL OFF,
FLAG, AWB, CALL, ZOOM(T),
ZOOM(W)
Assigns functions executed when you press the RET
2 button.
Note
INCOM1 and INCOM2 are displayed on the UCJ
model only. ENG and PROD are displayed instead on
the CE model.
INSIDE CALL OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, INCOM1,
INCOM2, EXTENDER,
D.EXTENDER, 5600K, VF DETAIL,
SPIRIT LEVEL INDICATOR, FOCUS
ASSIST INDICATOR, PinP, VF
ASSIGN SW1, VF ASSIGN SW2,
RET1 SW TOGGLE, RET2 SW
TOGGLE, RET3 SW TOGGLE, VTR
S/S, TALLY R, TALLY G, TALLY Y,
FAN MAX, CURSOR ALL OFF,
FLAG, AWB, CALL
, ZOOM(T),
ZOOM(W)
Assigns functions executed when you press the
CALL button.
Note
INCOM1 and INCOM2 are displayed on the UCJ
model only. ENG and PROD are displayed instead on
the CE model.
OPERATION
Page name
Page No.
Item Settings Description
