241
a) See page 148.
Modifying the wipe crop pattern edge
(Edge)
You can apply a border to the wipe crop pattern, or soften
the boundary.
1
In the <Edge> group of the Wipe Crop menu (4116),
select one of the following.
Border: Border
Soft: Soft edge
Soft Border: Soft border
2
Depending on the selection in step 1, set the following
parameters.
When [Border] is selected
When [Soft] is selected
When [Soft Border] is selected
Setting the signal or color to be inserted in
the wipe crop border
When a border or soft border is applied to a wipe crop, you
can set the signal or color to be inserted in the border.
1
In the <Border Fill> group of the Wipe Crop menu
(4116), select one of the following.
Flat Color: Single color
Mix Color: Mix color signal set in the DME >Edge
>Color Mix menu (4117) (see page 241)
Ext Video: External video signal input from Ext In
2
When [Flat Color] is selected in step 1, set the
following parameters.
Color Mix Settings
Creating a combination pattern
To select a pattern
1
Open the DME >Edge >Color Mix menu (4117).
2
Press [Mix Pattern Select].
The Mix Pattern Select menu (4117.1) appears.
3
Press any of the displayed patterns (standard wipe
patterns 1 to 24) to select it.
You can adjust the size and softness of the pattern
using the [Size] parameter and [Soft] parameter.
To set the pattern size and position
1
In the Color Mix menu (4117), press [Position/Size].
2
Set the following parameters.
To invert the regions of the two colors
In the Color Mix menu (4117), press [Color Invert],
turning it on.
Adjusting color 1 and color 2
1
In the Color Mix menu (4117), press [Color1] to adjust
color 1, or [Color2] to adjust color 2.
2
Set the following parameters.
2 V Multi Number of repetitions of pattern
vertically
3 Invert Type Pattern layout
a)
No. Parameter Adjustment
1 Width Border width
No. Parameter Adjustment
1 Soft Edge softness
No. Parameter Adjustment
1 Width Border width
2 Inner Soft Degree of softness inside the
border
3 Outer Soft Degree of softness outside the
border
No. Parameter Adjustment
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
No. Parameter Adjustment
1 H Horizontal position
2 V Vertical position
3 Size Pattern size
4 Soft Softness of the pattern
5 Pattern Pattern number
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
