To check the snapshot region: Press the
[SNAPSHOT] button, turning it on.
To check the effects region: Press the [EFF] button,
turning it on.
3
Press and hold the [STORE] button.
While the button is pressed, the button for the saved
region lights amber.
Shotbox Register Creation (Menu)
Creating a shotbox register
1
Open the Shotbox >Register >Store/Recall menu
(6411).
The status area shows the following information for
each register.
Register: Displays the shotbox register number and
name.
Lock status: Displays “L” when the register is locked
(write-protected).
Register empty status: Displays “E” when the
register is empty.
Auto run setting: Displays “AR” when auto run is
enabled.
Region settings: Displays “Sxxx” if a snapshot is
registered, and displays “Exxx” if an effect is
registered (where xxx is the register number).
Displays “KSS” when a key snapshot is registered.
2
Switch the region display as required.
Press the button corresponding to the region you want
to display.
M/E: M/E-1 (“ME1”), M/E-2 (“ME2”), M/E-3
(“ME3”), M/E-4 (“ME4”), M/E-5 (“ME5”)
P/P: PGM/PST (“P/P”)
User: User1 (“USR1”), User2 (“USR2”), User3
(“USR3”), User4 (“USR4”), User5 (“USR5”),
User6 (“USR6”), User7 (“USR7”), User8
(“USR8”)
DME: DME ch1 (“DME1”), ch2 (“DME2”), ch3
(“DME3”), ch4 (“DME4”)
DEV1-8: Device1 (“DEV1”), Device2 (“DEV2”),
Device3 (“DEV3”), Device4 (“DEV4”), Device5
(“DEV5”), Device6 (“DEV6”), Device7
(“DEV7”), Device8 (“DEV8”)
DEV9-12: Device9 (“DEV9”), Device10 (“DEV10”),
Device11 (“DEV11”), Device12 (“DEV12”)
Misc: P-Bus (“PBUS”), GPI (“GPI”), Router
(“RTR”), Macro (“MCRO”)
3
In the status area, select the target register to set.
4
Press [Edit].
The Edit menu (6411.1) appears.
You can also select the register in this menu using the
[Shotbox Reg] parameter.
The status area shows the information for the selected
shotbox register and the region selection buttons.
5
Press a region selection button to select a region.
You can select more than one region.
To select all regions, press [ALL]. To select all
switcher-related regions (M/E, P/P, User), press [SWR
ALL].
6
In the <Assign> group, select a snapshot or effect.
Snapshot: Set a snapshot. Select the register to
register using the following parameter.
Effect: Set an effect. Select the register to register
using the following parameter.
The region selection button shows the selected register
number.
7
Repeat steps 5 and 6 as required to set all snapshots/
effects to be registered in the shotbox register.
8
To enable auto run, press [Auto Run], turning it on.
When auto run is enabled, the effects are executed at
the same time the register is recalled.
9
In the <Store> group, press [Store].
To return to the state before saving the setting
In the <Store> group, press [Undo].
Registering key snapshots in a shotbox
register
Only a snapshot/effect or a key snapshot can be set in an
M/E region.
1
In the Shotbox >Register >Store/Recall menu (6411),
select the target register to set.
2
Press [Key Snapshot Edit].
The Key Snapshot Edit menu (6411.2) appears.
You can also select the register in this menu using the
[Shotbox Reg] parameter.
No. Parameter Adjustment
3 Snapshot Snapshot register number
No. Parameter Adjustment
3 Effect Effect register number
