Sony ICP-X7000 - Status Menu; DME Menu

To Next Page

To Previous Page

507

Status Menu

DME Menu

Menu (Page No.) Default Recall

VF1: DME Status (3311) – –

Menu (Page No.) Default Recall

Status (4100) – –

VF1: Edge HF1: Border/Crop (4111) Yes

HF2: Beveled Edge (4112) Yes

HF3: Key Border (4113) Yes

HF4: Art Edge (4114) Yes

HF5: Flex Shadow (4115) Yes

HF6: Wipe Crop (4116) Yes

Pattern Select (4116.1) Yes

HF7: Color Mix (4117) Yes

Mix Pattern Select (4117.1) Yes

VF2: Video Modify HF1: Defocus/Blur (4121) Yes

Mask (4127) Yes

HF2: Multi Move (4122) Yes

HF3: Color Modify (4123) Yes

Mask (4127) Yes

HF4: Mosaic (4124) Yes

Mask (4127) Yes

HF7: Mask (4127) Yes

VF3: Freeze HF1: Freeze (4131) Yes
