431
name set on the router or an NS-Bus alias name set on the
system controller.
The source name is updated each time the description
name/alias name is updated. This allows you to always use
the same name between the router/system controller and
the switcher.
The S-Bus description name/NS-Bus alias name is
reflected in the source name setting in the Xpt Assign
menu, hence the name set on the router/system controller
is also displayed when [Sw’er Local] is selected in the
<Source/Dest Name> group.
To enable the link function for S-Bus
In the Engineering Setup >Panel >Operation menu (7326),
press [S-Bus Name Link], turning it on.
To enable the link function for NS-Bus
In the Engineering Setup >Panel >Operation menu (7326),
press [NS-Bus Name Link], check the message, then press
[Yes].
• When [NS-Bus Name Link] is enabled, the settings of all
source names for the switcher (including wiring
traceback), not just in the Xpt Assign menu, are always
replaced by the NS-Bus alias name.
• To display the NS-Bus alias name on a multi viewer sub
screen, you must select [NS-Bus Alias] in the <Source/
Dest Name> group and enable [NS-Bus Name Link].
Setting Flexi Pad Control Block
Button Display and Operation
In the Engineering Setup >Panel >Operation menu (7326),
press [Flexi Pad Mode] to open the Flexi Pad Mode menu
(7326.3).
Configure each function, as required.
Linking the transition type selection with the
Flexi Pad control block operation mode
Press [Wipe/DME Auto Deleg], turning it on.
This switches the operation mode of the Flexi Pad control
block in sync with the selection of the [WIPE] button or
[DME WIPE] button on the transition control block.
Setting the memory recall button display in wipe
snapshot operation mode and DME wipe
snapshot operation mode
In the <Wipe/DME Display> group, select one of the
following.
Pattern: Pattern image display
Register Name: Register name display
Setting the memory recall button display in
snapshot operation mode and effect operation
mode
In the <Snapshot/Effect Display> group, select one of the
following.
Register No.: Register number display
Register Name: Register name display
Assigning a register to bottom left button of bank
0
In the <Bank 0 Register Assign> group, select one of the
following.
Register Assign: Assign a register. Select the register
number using the following parameter.
a) 1 to 99 configurable only
Register No Assign: Disable register assignment.
The bottom left button of bank 0 cannot be selected in the
Misc >Snapshot menu on each switcher bank.
Setting the Button and Fader Lever
Operation Mode
In the Engineering Setup >Panel >Operation menu (7326),
press [Custom Button/Fader] to open the Custom Button/
Fader menu (7326.4).
Configure each function, as required.
Setting the double-press operation mode of the
[BKGD] button in the transition control block
In the <Bkgd Trans Btn Double Clk> group, select one of
the following.
Disable: Double-pressing of the [BKGD] button is
disabled.
Enable: When the [BKGD] button is pressed twice in
quick succession, all currently inserted keys are
selected and removed by the next transition.
Setting the operation mode when the [FTB]
button is pressed during fade-to-black
In the <FTB> group, select one of the following.
Continue: Continue the fade-to-black.
Cancel: Cancel the fade-to-black, and return to the
previous state.
Setting the operation mode when the [AUTO
TRANS] button or [TAKE] button is pressed
during an auto transition
In the <Auto Trans/Take> group, select one of the
following.
Notes
No. Parameter Adjustment
1Register
No.
Register number
a)
Note
