426
a) The safe title enable/disable commands display the name of the signal
assigned to the output.
Setting names to display in memory recall
buttons
You can set the display of names on buttons when menu
shortcuts or utility commands are assigned to the memory
recall buttons.
When a macro register is assigned, the names specified in
the Macro menu are displayed on the memory recall
buttons. When a shotbox register is assigned, the names
specified in the Shotbox menu are displayed on the
memory recall buttons.
1
In the Engineering Setup >Panel >Prefs/Utility
>Utility Module Assign menu (7324.1), select the
target button to set.
2
Press [Name].
Macro All Take Resume all paused macros in multi mode Pause during
execution (lit purple)
• Executing (lit light
purple)
• Function assigned
(gray characters on
black background)
Macro Auto Ins Macro auto insert mode enable/disable Enabled Disabled
Macro Cancel Stop macro execution Stop execution (lit
light purple only at the
instant the button is
pressed)
Function assigned (lit
purple)
Macro All Cancel Stop all simultaneous executing macros in
multi mode
Stop execution (lit
light purple only at the
instant the button is
pressed)
Function assigned (lit
purple)
DME Override DME override enable/disable Enabled Disabled
DME Graphic DME graphics enable/disable
(applies to graphics for channel selected in
device control block)
Enabled Disabled
FTB Fade-to-black execution • Executing (lit light
purple)
• Lit red when
execution
completed (image
in black state)
Function assigned (lit
purple)
AUTO PVW Auto preview Output on the edit
preview bus
Function assigned
PRESET PVW Preset preview Output on the edit
preview bus
Function assigned
P/P PVW P/P preview output Output on the edit
preview bus
Function assigned
M/Ex PVW M/E-x preview output
x = 1 to 5
Output on the edit
preview bus
Function assigned
P/P KPVW1 P/P key preview 1 output Output on the edit
preview bus
Function assigned
M/Ex KPVW1 M/E-x key preview 1 output
x = 1 to 5
Output on the edit
preview bus
Function assigned
P/P KPVW2 P/P key preview 2 output Output on the edit
preview bus
Function assigned
M/Ex KPVW2 M/E-x key preview 2 output
x = 1 to 5
Output on the edit
preview bus
Function assigned
Command name Function Button state
Lit orange Lit dark blue
Note
