Sony KD-32NS100B - VM Board, Complete

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 100 -
R8800 1-247-895-91 CARBON 470K 5% 1/4W
R8804 1-249-408-11 CARBON 180 5% 1/4W
R8805 1-249-408-11 CARBON 180 5% 1/4W
R8806 1-249-411-11 CARBON 330 5% 1/4W
R8807 1-249-411-11 CARBON 330 5% 1/4W
R8808 1-260-340-11 CARBON 10K 5% 1/2W
R8809 1-260-340-11 CARBON 10K 5% 1/2W
R8810 1-215-895-11 METAL OXIDE 3.3K 5% 2W
R8811 1-215-896-00 METAL OXIDE 4.7K 5% 2W
R8812 1-215-896-00 METAL OXIDE 4.7K 5% 2W
R8813 1-216-460-11 METAL OXIDE 3.9K 5% 2W
R8814 1-215-880-00 METAL OXIDE 10 5% 2W
R8815 1-215-880-00 METAL OXIDE 10 5% 2W
R8816 1-216-365-00 METAL OXIDE 0.47 5% 2W
R8817 1-216-361-00 METAL OXIDE 0.22 5% 2W
R8818 1-249-405-11 CARBON 100 5% 1/4W
R8819 1-247-807-31 CARBON 100 5% 1/4W
R8831 1-260-124-11 CARBON 120K 5% 1/2W
R8833 1-202-972-61 FUSIBLE 1 5% 1/4W
R8834 1-260-288-11 CARBON 0.47 5% 1/2W
R8835 1-260-288-11 CARBON 0.47 5% 1/2W
R8836 1-249-429-11 CARBON 10K 5% 1/4W
R8837 1-215-894-11 METAL OXIDE 2.2K 5% 2W
R8838 1-214-905-11 METAL 47K 1% 1/2W
R8839 1-215-894-11 METAL OXIDE 2.2K 5% 2W
R8840 1-249-421-11 CARBON 2.2K 5% 1/4W
R8842 1-260-123-11 CARBON 100K 5% 1/2W
R8843 1-216-833-11 RES-CHIP 10K 5% 1/16W
R8844 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8845 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8851 1-260-123-11 CARBON 100K 5% 1/2W
R8852 1-260-123-11 CARBON 100K 5% 1/2W
R8853 1-260-123-11 CARBON 100K 5% 1/2W
R8854 1-249-425-11 CARBON 4.7K 5% 1/4W
R8856 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R8857 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R8858 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R8859 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R8865 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8866 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8867 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8885 1-208-854-11 METAL CHIP 1M 0.5% 1/10W
R8886 1-218-760-11 METAL CHIP 220K 0.5% 1/10W
R8887 1-216-841-11 RES-CHIP 47K 5% 1/16W
R8888 1-249-441-11 CARBON 100K 5% 1/4W
R8895 1-249-443-11 CARBON 0.47 5% 1/4W
R8896 1-249-443-11 CARBON 0.47 5% 1/4W
R8897 1-215-489-00 METAL 680K 1% 1/4W
R8898 1-215-493-00 METAL 1M 1% 1/4W
R8899 1-215-493-00 METAL 1M 1% 1/4W
D
VM
< TRANSFORMER >
T8800 £ 1-453-383-11 TRANSFORMER ASSY, FLYBACK (NX-4522//Z214)
T8801 1-437-430-11 TRANSFORMER, FERRITE (HDT)
T8802 1-437-430-11 TRANSFORMER, FERRITE (HDT)
T8852 1-433-487-11 TRANSFORMER, FERRITE (DFT)
*A-1644-126-A VM Board, Complete
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C5400 1-107-883-11 ELECT 330UF 20.00% 16V
C5401 1-126-935-11 ELECT 470UF 20.00% 16V
C5402 1-137-150-11 MYLAR 0.01UF 5.00% 50V
C5403 1-126-935-11 ELECT 470UF 20.00% 6.3V
C5405 1-126-933-11 ELECT 100UF 20.00% 16V
C5406 1-126-935-11 ELECT 470UF 20.00% 6.3V
C5407 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C5408 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C5409 1-107-649-11 ELECT 2.2UF 20.00% 250V
C5410 1-130-471-00 MYLAR 0.001UF 5.00% 50V
C5411 1-130-471-00 MYLAR 0.001UF 5.00% 50V
C5412 1-126-935-11 ELECT 470UF 20.00% 16V
C5413 1-126-935-11 ELECT 470UF 20.00% 16V
C5414 1-107-652-11 ELECT 10UF 20.00% 250V
C5415 1-107-363-91 MYLAR 0.0068UF 10.00% 200V
C5417 1-102-514-11 CERAMIC 22PF 5.00% 50V
C5418 1-102-947-00 CERAMIC 10PF 0.50PF 50V
< CONNECTOR >
CN5402 *1-564-506-11 PLUG, CONNECTOR 3P
CN5444 *1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
CN5602 *1-564-508-11 PLUG, CONNECTOR 5P
< DIODE >
D5400 8-719-991-33 DIODE 1SS133T-77
D5401 8-719-510-02 DIODE D1NS4
D5402 1-535-143-61 LEAD, JUMPER (5.0MM)
D5403 8-719-991-33 DIODE 1SS133T-77
D5404 8-719-991-33 DIODE 1SS133T-77
D5405 8-719-924-11 DIODE MTZJ-T-77-22
D5406 8-719-924-11 DIODE MTZJ-T-77-22
< FERRITE BEAD >
FB5400 1-535-143-61 LEAD, JUMPER (5.0MM)
FB5401 1-535-143-61 LEAD, JUMPER (5.0MM)
