Sony KD-32NS100B - L Board, Complete (KD-32 NS100)

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 109 -
H3
L
< COIL >
L7925 1-414-183-41 INDUCTOR 10UH
L7926 1-414-183-41 INDUCTOR 10UH
*A-1646-258-A L Board, Complete (KD-32NS100)
< CAPACITOR >
C1001 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C1002 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C1003 1-126-964-11 ELECT 10UF 20.00% 50V
C1004 1-164-388-91 CERAMIC CHIP 270PF 5.00% 50V
C1005 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1006 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1007 1-126-964-11 ELECT 10UF 20.00% 50V
C1008 1-164-492-11 CERAMIC CHIP 0.15UF 10.00% 16V
C1009 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C1010 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C1011 1-162-969-11 CERAMIC CHIP 0.0068UF 10.00% 25V
C1012 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C1013 1-162-969-11 CERAMIC CHIP 0.0068UF 10.00% 25V
C1015 1-164-492-11 CERAMIC CHIP 0.15UF 10.00% 16V
C1016 1-164-388-91 CERAMIC CHIP 270PF 5.00% 50V
C1017 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1019 1-126-964-11 ELECT 10UF 20.00% 50V
C1023 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1024 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1025 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1026 1-126-964-11 ELECT 10UF 20.00% 50V
C1027 1-125-837-91 CERAMIC CHIP 1UF 10% 6.3V
C1028 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C1029 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1030 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C1031 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1032 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1033 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1036 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1037 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
C1039 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1040 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1041 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1042 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C1043 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1044 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C1045 1-104-514-11 MYLAR 0.22UF 10.00% 250V
C1046 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1047 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1048 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1049 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1052 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1053 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1054 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1055 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1056 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1057 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1058 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1059 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1060 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1061 1-126-964-11 ELECT 10UF 20.00% 50V
C1062 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1063 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C1064 1-162-969-11 CERAMIC CHIP 0.0068UF 10.00% 25V
C1065 1-126-961-11 ELECT 2.2UF 20.00% 50V
C1068 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C1069 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C1072 1-126-964-11 ELECT 10UF 20.00% 50V
C1074 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C1075 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C1076 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
< CONNECTOR >
CN1000 1-785-720-11 JACK, TELEPHONE
CN1002 *1-764-333-11 PLUG, CONNECTOR 10P
CN1004 1-779-961-11 PIN, CONNECTOR (WITH PWB) 10P
< DIODE >
D1004 8-719-977-81 DIODE UDZ-TE-17-33B
D1005 8-719-064-76 DIODE MB6S
< FERRITE BEAD >
FB001 1-469-458-91 INDUCTOR 0UH
< FILTER >
FL1005 1-469-458-91 INDUCTOR 0UH
FL1006 1-469-458-91 INDUCTOR 0UH
< IC >
IC1001 8-759-595-38 IC CSP1034AHJ-11-DB
IC1004 8-759-347-45 IC AS7C3256-15JC-T
IC1005 8-759-347-45 IC AS7C3256-15JC-T
IC1006 8-759-696-42 IC 1673TV8-28RDD-DB
IC1009 8-759-667-76 IC M29F400BB70N1
ISO100 8-749-011-34 PHOTO COUPLER TLP181(TPR)
ISO101 8-749-011-34 PHOTO COUPLER TLP181(TPR)
ISO104 8-749-011-34 PHOTO COUPLER TLP181(TPR)
ISO105 8-719-054-40 PHOTO COUPLER TLP127(TPL)
