Sony KD-32NS100B - F3 Board, Complete (KD-32 DX100); H5 Board, Complete (KD-32 DX100); H6 Board, Complete (KD-32 DX100)

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 74 -
*A-1624-085-A F3 Board, Complete (KD-32DX100)
< CONNECTOR >
CN7700 £ *1-695-292-11 PIN, CONNECTOR (POWER)
CN7733 £ *1-580-844-11 PIN, CONNECTOR (POWER)
< SWITCH >
S7751 £ 1-571-433-31 SWITCH, PUSH (AC POWER)
*A-1646-210-A H5 Board, Complete (KD-32DX100)
< CAPACITOR >
C7900 1-101-810-00 CERAMIC 100PF 5.00% 500V
C7901 1-101-810-00 CERAMIC 100PF 5.00% 500V
C7925 1-137-372-11 MYLAR 0.022UF 5.00% 50V
C7926 1-137-372-11 MYLAR 0.022UF 5.00% 50V
< CONNECTOR >
CN7102 *1-564-518-11 PLUG, CONNECTOR 3P
CN7103 *1-564-526-11 PLUG, CONNECTOR 11P
< JACK >
J7900 1-794-442-11 TERMINAL BLOCK (LIGHT ANGLE),S
J7925 1-785-448-11 JACK
< COIL >
L7925 1-414-183-41 INDUCTOR 10UH
L7926 1-414-183-41 INDUCTOR 10UH
< RESISTOR >
R7100 1-249-425-11 CARBON 4.7K 5% 1/4W
R7101 1-249-429-11 CARBON 10K 5% 1/4W
R7102 1-249-421-11 CARBON 2.2K 5% 1/4W
R7103 1-249-429-11 CARBON 10K 5% 1/4W
R7104 1-249-425-11 CARBON 4.7K 5% 1/4W
R7105 1-249-421-11 CARBON 2.2K 5% 1/4W
R7900 1-535-143-61 LEAD, JUMPER (5.0MM)
R7901 1-249-417-11 CARBON 1K 5% 1/4W
R7902 1-247-895-91 CARBON 470K 5% 1/4W
R7903 1-247-895-91 CARBON 470K 5% 1/4W
R7904 1-535-143-61 LEAD, JUMPER (5.0MM)
R7905 1-249-417-11 CARBON 1K 5% 1/4W
R7906 1-535-143-61 LEAD, JUMPER (5.0MM)
< SWITCH >
S7100 1-771-947-11 SWITCH, TACTILE
S7101 1-771-947-11 SWITCH, TACTILE
S7102 1-771-947-11 SWITCH, TACTILE
*A-1646-259-A H6 Board, Complete (KD-32DX100)
< CAPACITOR >
C7150 1-126-969-11 ELECT 220UF 20.00% 50V
< CONNECTOR >
CN7100 *1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D7150 8-719-081-56 DIODE L-59SRSGC-CC
4-205-711-01 HOLDER LED (D7150)
< IC >
IC7150 8-749-014-59 IC TSOP1740KS1
< TRANSISTOR >
Q7150 8-729-029-56 TRANSISTOR DTA144ESA
Q7151 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R7150 1-249-409-11 CARBON 220 5% 1/4W
R7151 1-249-411-11 CARBON 330 5% 1/4W
R7152 1-249-437-11 CARBON 47K 5% 1/4W
R7153 1-249-389-11 CARBON 4.7 5% 1/4W
R7154 1-249-385-11 CARBON 2.2 5% 1/4W
R7155 1-247-807-31 CARBON 100 5% 1/4W
R7156 1-249-411-11 CARBON 330 5% 1/4W
*A-1620-152-A B4 Board, Complete
< CAPACITOR >
C333 1-216-295-91 SHORT 0
C368 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C369 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C372 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C373 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C374 1-126-603-11 ELECT CHIP 4.7UF 20.00% 35V
C375 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C376 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C377 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C378 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C501 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C502 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C503 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C505 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C507 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C509 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C510 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
