Sony KD-32NS100B - J1 Board, Complete

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 101 -
< COIL >
L5400 1-410-784-41 INDUCTOR 0.18UH
L5401 1-408-602-31 INDUCTOR 8.2UH
< TRANSISTOR >
Q5400 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q5401 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q5402 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q5403 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q5404 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q5405 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q5406 8-729-045-05 TRANSISTOR 2SA2005
Q5407 8-729-045-04 TRANSISTOR 2SC5511
Q5408 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q5409 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R5401 1-247-843-11 CARBON 3.3K 5% 1/4W
R5402 1-249-413-11 CARBON 470 5% 1/4W
R5403 1-249-393-11 CARBON 10 5% 1/4W
R5404 1-249-420-11 CARBON 1.8K 5% 1/4W
R5405 1-249-425-11 CARBON 4.7K 5% 1/4W
R5406 1-249-425-11 CARBON 4.7K 5% 1/4W
R5407 1-249-399-11 CARBON 33 5% 1/4W
R5408 1-247-807-31 CARBON 100 5% 1/4W
R5409 1-249-409-11 CARBON 220 5% 1/4W
R5410 1-249-401-11 CARBON 47 5% 1/4W
R5411 1-249-401-11 CARBON 47 5% 1/4W
R5412 1-249-429-11 CARBON 10K 5% 1/4W
R5413 1-249-414-11 CARBON 560 5% 1/4W
R5414 1-249-432-11 CARBON 18K 5% 1/4W
R5415 1-260-316-51 CARBON 100 5% 1/2W
R5416 1-249-388-11 CARBON 3.9 5% 1/4W
R5417 1-249-432-11 CARBON 18K 5% 1/4W
R5418 1-249-414-11 CARBON 560 5% 1/4W
R5419 1-249-421-11 CARBON 2.2K 5% 1/4W
R5420 1-249-421-11 CARBON 2.2K 5% 1/4W
R5421 1-249-386-11 CARBON 2.7 5% 1/4W
R5422 1-249-405-11 CARBON 100 5% 1/4W
R5423 1-215-915-11 METAL OXIDE 470 5% 3W
R5425 1-535-143-61 LEAD, JUMPER (5.0MM)
R5427 1-249-401-11 CARBON 47 5% 1/4W
R5428 1-249-413-11 CARBON 470 5% 1/4W
R5429 1-249-413-11 CARBON 470 5% 1/4W
R5430 1-249-417-11 CARBON 1K 5% 1/4W
R5432 1-249-415-11 CARBON 680 5% 1/4W
R5433 1-249-400-11 CARBON 39 5% 1/4W
R5434 1-249-395-11 CARBON 15 5% 1/4W
*A-1651-144-A J1 Board, Complete
< CAPACITOR >
C8105 1-126-933-11 ELECT 100UF 20.00% 16V
C8106 1-126-933-11 ELECT 100UF 20.00% 16V
C8107 1-126-935-11 ELECT 470UF 20.00% 16V
C8108 1-126-933-11 ELECT 100UF 20.00% 16V
C8109 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8110 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8111 1-126-933-11 ELECT 100UF 20.00% 16V
C8800 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8801 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C8802 1-126-947-11 ELECT 47UF 20.00% 25V
C8803 1-126-947-11 ELECT 47UF 20.00% 25V
C8804 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8805 1-126-947-11 ELECT 47UF 20.00% 25V
C8807 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C8808 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8809 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C8810 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8811 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8812 1-126-961-11 ELECT 2.2UF 20.00% 50V
C8813 1-126-947-11 ELECT 47UF 20.00% 25V
C8814 1-126-947-11 ELECT 47UF 20.00% 25V
C8815 1-126-947-11 ELECT 47UF 20.00% 25V
C8816 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8817 1-126-964-11 ELECT 10UF 20.00% 50V
C8818 1-126-947-11 ELECT 47UF 20.00% 25V
C8819 1-107-682-11 CERAMIC CHIP 1UF 10.00% 16V
C8820 1-126-947-11 ELECT 47UF 20.00% 25V
C8821 1-164-346-11 CERAMIC CHIP 1UF 16V
C8822 1-126-963-11 ELECT 4.7UF 20.00% 50V
C8824 1-163-247-91 CERAMIC CHIP 68PF 5.00% 50V
C8825 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8826 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C8827 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8828 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8829 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C8830 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8831 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8832 1-126-947-11 ELECT 47UF 20.00% 25V
C8833 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8834 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8835 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8836 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8837 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8838 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8839 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8840 1-164-156-11 CERAMIC CHIP 0.1UF 25V
VM J1
