Sony KD-32NS100B - H1 Board, Complete; H2 Board, Complete; H3 Board, Complete

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 108 -
H2 H3
S7104 1-692-431-21 SWITCH, TACTILE
S7105 1-692-431-21 SWITCH, TACTILE
S7106 1-692-431-21 SWITCH, TACTILE
*A-1646-248-A H2 Board, Complete (KD-32NS100/
KD-32NX100)
4-205-711-01 HOLDER, LED
< CAPACITOR >
C7150 1-126-969-11 ELECT 220UF 20.00% 50V
< CONNECTOR >
CN7150 *1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D7150 8-719-081-56 DIODE L-59SRSGC-CC
D7152 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC7150 8-742-180-30 HYB IC SBX3081-51(20)
< TRANSISTOR >
Q7150 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q7151 8-729-029-66 TRANSISTOR DTC114ESA-TP
< RESISTOR >
R7150 1-249-409-11 CARBON 220 5% 1/4W
R7151 1-249-411-11 CARBON 330 5% 1/4W
R7152 1-249-437-11 CARBON 47K 5% 1/4W
R7153 1-249-425-11 CARBON 4.7K 5% 1/4W
R7154 1-249-421-11 CARBON 2.2K 5% 1/4W
R7155 1-247-807-31 CARBON 100 5% 1/4W
R7156 1-249-411-11 CARBON 330 5% 1/4W
*A-1646-249-A H3 Board, Complete (KD-32NS100/
KD-32NX100)
< CAPACITOR >
C7925 1-137-372-11 MYLAR 0.022UF 5.00% 50V
C7926 1-137-372-11 MYLAR 0.022UF 5.00% 50V
< CONNECTOR >
CN7104 *1-564-518-11 PLUG, CONNECTOR 3P
< JACK >
J7925 1-785-448-11 JACK
H1
F1
< FUSE >
F5401 £ 1-576-232-21 FUSE (H.B.C.) 5A/250V
*1-533-725-11 HOLDER, FUSE (F5401)
< RESISTOR >
R401 £ 1-202-719-00 SOLID 1M 10% 1/2W
< SWITCH >
S401 £ 1-571-433-21 SWITCH, PUSH (AC POWER)
< VARISTOR >
VD401 £ 1-803-830-11 VARISTOR (ERZV14D621)
*A-1646-247-A H1 Board, Complete (KD-32NS100/
KD-32NX100)
< CAPACITOR >
C7900 1-101-810-00 CERAMIC 100PF 5.00% 500V
C7901 1-101-810-00 CERAMIC 100PF 5.00% 500V
C7902 1-101-810-00 CERAMIC 100PF 5.00% 500V
C7903 1-101-810-00 CERAMIC 100PF 5.00% 500V
< CONNECTOR >
CN7102 *1-564-518-11 PLUG, CONNECTOR 3P
CN7103 *1-564-522-11 PLUG, CONNECTOR 7P
< JACK >
J7900 1-779-947-11 TERMINAL BLOCK, S
< RESISTOR >
R7100 1-249-429-11 CARBON 10K 5% 1/4W
R7101 1-249-425-11 CARBON 4.7K 5% 1/4W
R7102 1-249-421-11 CARBON 2.2K 5% 1/4W
R7103 1-249-429-11 CARBON 10K 5% 1/4W
R7104 1-249-425-11 CARBON 4.7K 5% 1/4W
R7105 1-249-421-11 CARBON 2.2K 5% 1/4W
R7900 1-535-143-61 LEAD, JUMPER (5.0MM)
R7901 1-249-417-11 CARBON 1K 5% 1/4W
R7902 1-247-895-91 CARBON 470K 5% 1/4W
R7903 1-247-895-91 CARBON 470K 5% 1/4W
R7904 1-535-143-61 LEAD, JUMPER (5.0MM)
R7905 1-249-417-11 CARBON 1K 5% 1/4W
R7906 1-535-143-61 LEAD, JUMPER (5.0MM)
< SWITCH >
S7101 1-692-431-21 SWITCH, TACTILE
S7102 1-692-431-21 SWITCH, TACTILE
S7103 1-692-431-21 SWITCH, TACTILE
