Sony KD-32NS100B - C Board, Complete

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 95 -
C
G
< PHOTO COUPLER >
PH6001 £ 8-749-016-21 IC TCET1103G
< TRANSISTOR >
Q6003 8-729-010-29 TRANSISTOR MSD601-RST1
Q6005 8-729-029-56 TRANSISTOR DTA144ESA
Q6006 8-729-056-60 TRANSISTOR SPA07N60C2
Q6007 8-729-056-60 TRANSISTOR SPA07N60C2
Q6010 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q6101 8-729-029-56 TRANSISTOR DTA144ESA
Q6102 8-729-010-29 TRANSISTOR MSD601-RST1
Q6103 8-729-029-56 TRANSISTOR DTA144ESA
Q6104 8-729-010-29 TRANSISTOR MSD601-RST1
Q6105 8-729-010-29 TRANSISTOR MSD601-RST1
< RESISTOR >
JR6004 1-216-295-91 SHORT 0
R6003 £ 1-202-933-61 FUSIBLE 0.1 10% 1/2W
R6004 £ 1-205-998-11 CEMENTED 1 5% 10W
R6005 £ 1-205-998-11 CEMENTED 1 5% 10W
R6006 £ 1-205-998-11 CEMENTED 1 5% 10W
R6007 1-243-979-21 METAL OXIDE 0.1 5% 2W
R6008 1-243-979-21 METAL OXIDE 0.1 5% 2W
R6009 1-208-810-11 METAL CHIP 15K 0.5% 1/10W
R6010 1-215-481-00 METAL 330K 1% 1/4W
R6011 1-535-143-71 LEAD, JUMPER (7.5MM)
R6013 £ 1-218-265-11 METAL 8.2M 5% 1W
R6014 1-215-926-00 METAL OXIDE 33K 5% 3W
R6015 1-208-757-11 METAL CHIP 91 0.5% 1/10W
R6016 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6017 1-216-833-11 RES-CHIP 10K 5% 1/16W
R6018 1-247-895-91 CARBON 470K 5% 1/4W
R6019 1-247-891-00 CARBON 330K 5% 1/4W
R6020 1-216-820-11 RES-CHIP 820 5% 1/16W
R6021 1-216-362-11 METAL OXIDE 0.27 5% 2W
R6022 1-216-833-11 RES-CHIP 10K 5% 1/16W
R6024 1-216-615-11 METAL CHIP 33 0.5% 1/10W
R6028 1-249-389-11 CARBON 4.7 5% 1/4W
R6029 1-216-833-11 RES-CHIP 10K 5% 1/16W
R6030 1-216-817-11 RES-CHIP 470 5% 1/16W
R6032 1-249-417-11 CARBON 1K 5% 1/4W
R6033 1-215-481-00 METAL 330K 1% 1/4W
R6035 1-260-083-11 CARBON 47 5% 1/2W
R6036 1-216-817-11 RES-CHIP 470 5% 1/16W
R6037 1-249-405-11 CARBON 100 5% 1/4W
R6038 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
R6039 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
R6040 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R6042 1-216-295-91 SHORT 0
R6045 1-208-770-11 METAL CHIP 330 0.5% 1/10W
R6047 1-208-842-11 METAL CHIP 330K 0.5% 1/10W
R6048 1-215-481-00 METAL 330K 1% 1/4W
R6049 1-208-805-11 METAL CHIP 9.1K 0.5% 1/10W
R6050 1-208-758-11 METAL CHIP 100 0.5% 1/10W
R6054 1-216-615-11 METAL CHIP 33 0.5% 1/10W
R6056 1-216-295-91 SHORT 0
R6101 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6102 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6103 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6104 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6105 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6106 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6107 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6108 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6109 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6110 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6111 1-535-143-71 LEAD, JUMPER (7.5MM)
< RELAY >
RY6001 £ 1-755-395-11 RELAY (AC POWER)
RY6002 £ 1-755-389-11 RELAY (AC POWER)
< TRANSFORMER >
T6001 £ 1-431-402-11 TRANSFORMER, LINE FILTER
T6002 £ 1-437-443-11 TRANSFORMER, CONVERTER (PIT)
T6003 £ 1-431-402-11 TRANSFORMER, LINE FILTER
T6101 £ 1-437-483-11 TRANSFORMER, STANDBY
< THERMISTOR >
TH6002 £ 1-803-540-11 THERMISTOR
*A-1638-162-A C Board, Complete
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C5301 1-163-075-00 CERAMIC CHIP 0.047UF 50V
C5302 1-128-528-11 ELECT 470UF 20.00% 16V
C5303 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C5304 1-107-967-11 ELECT 1UF 20.00% 400V
C5305 1-136-207-11 MYLAR 0.047UF 10.00% 400V
C5306 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C5307 1-163-233-91 CERAMIC CHIP 18PF 5.00% 50V
C5308 1-163-089-00 CERAMIC CHIP 6PF 0.50PF 50V
C5309 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C5310 1-163-247-91 CERAMIC CHIP 68PF 5.00% 50V
C5325 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C5326 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
