Sony KD-32NS100B - A Board, Common Parts; A Board, Complete (KD-32 DX100;; F Board, Complete (KD-32 DX100)

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 81 -
C1031 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1032 1-126-916-11 ELECT 1000UF 20.00% 6.3V
C1033 1-126-916-11 ELECT 1000UF 20.00% 6.3V
C1034 1-126-935-11 ELECT 470UF 20.00% 6.3V
C1035 1-126-935-11 ELECT 470UF 20.00% 6.3V
C1036 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1037 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1038 1-104-665-11 ELECT 100UF 20.00% 25V
C1039 1-104-665-11 ELECT 100UF 20.00% 25V
C1040 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1041 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1043 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C1044 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C1045 1-104-665-11 ELECT 100UF 20.00% 25V
C1046 1-104-665-11 ELECT 100UF 20.00% 25V
C1054 1-126-964-11 ELECT 10UF 20.00% 50V
C1055 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C1056 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C1057 1-126-933-11 ELECT 100UF 20.00% 16V
C1201 1-115-340-11 CERAMIC CHIP 0.22UF 10.00% 25V
C1202 1-126-947-11 ELECT 47UF 20.00% 25V
C1203 1-136-175-00 FILM 0.68UF 5.00% 50V
C1204 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1205 1-126-943-11 ELECT 2200UF 20.00% 25V
C1206 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1207 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1208 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1209 1-163-135-00 CERAMIC CHIP 560PF 5.00% 50V
C1210 1-126-965-91 ELECT 22UF 20.00% 50V
C1211 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1212 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1213 1-126-965-91 ELECT 22UF 20.00% 50V
C1214 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1215 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C1216 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C1217 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C1218 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1219 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1220 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1222 1-130-777-00 MYLAR 0.1UF 5.00% 63V
C1223 1-126-952-11 ELECT 1000UF 20.00% 35V
C1224 1-111-216-91 ELECT 150UF 20.00% 63V
C1225 1-164-222-91 CERAMIC CHIP 0.22UF 25V
C1226 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1227 1-126-952-11 ELECT 1000UF 20.00% 35V
C1228 1-126-961-11 ELECT 2.2UF 20.00% 50V
C1229 1-126-944-11 ELECT 3300UF 20.00% 25V
C1230 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1231 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C1232 1-126-947-11 ELECT 47UF 20.00% 25V
F
A
*A-1624-110-A F Board, Complete (KD-32DX100)
< CONNECTOR >
CN1001 £ 1-580-843-11 PIN, CONNECTOR (POWER)
CN1002 £ *1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
CN1003 £ 1-695-915-11 TAB (CONTACT)
CN1004 1-695-915-11 TAB (CONTACT)
< FUSE >
F1001 £ 1-576-232-11 FUSE (H.B.C.) 5A/250V
*1-533-725-11 HOLDER, FUSE (F1001)
< RESISTOR >
R1001 £ 1-202-719-00 SOLID 1M 20% 1/2W
< VARISTOR >
VDR101 £ 1-803-830-11 VARISTOR (ERZV14D621)
*A-1631-164-A A Board, Complete (KD-32DX100/
KD-32NX100)
*A-1631-170-A A Board, Complete (KD-32NS100)
A Board, Common Parts
4-201-023-01 SPACER, INSULATING
4-202-373-01 SPRING, IC
*4-206-352-01 SHEET, INSULATING
*4-206-387-01 SHIELD BASE, N
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C1002 1-126-935-11 ELECT 470UF 20.00% 10V
C1003 1-126-935-11 ELECT 470UF 20.00% 10V
C1006 1-136-495-11 FILM 0.068UF 5.00% 50V
C1007 1-136-495-11 FILM 0.068UF 5.00% 50V
C1008 1-104-665-11 ELECT 100UF 20.00% 25V
C1009 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1010 1-126-916-11 ELECT 1000UF 20.00% 6.3V
C1011 1-126-916-11 ELECT 1000UF 20.00% 6.3V
C1012 1-126-935-11 ELECT 470UF 20.00% 6.3V
C1013 1-126-935-11 ELECT 470UF 20.00% 6.3V
C1017 1-104-661-91 ELECT 330UF 20.00% 16V
C1018 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1020 1-126-933-11 ELECT 100UF 20.00% 16V
C1022 1-162-937-11 CERAMIC CHIP 100PF 5.00% 50V
C1023 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1024 1-126-935-11 ELECT 470UF 20.00% 10V
C1025 1-126-935-11 ELECT 470UF 20.00% 10V
C1028 1-104-665-11 ELECT 100UF 20.00% 25V
C1029 1-136-495-11 FILM 0.068UF 5.00% 50V
C1030 1-136-495-11 FILM 0.068UF 5.00% 50V
