REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 103 -
C8983 1-104-665-11 ELECT 100UF 20.00% 25V
C8984 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8986 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8987 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8988 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C8989 1-126-947-11 ELECT 47UF 20.00% 25V
C8990 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C8991 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C8992 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C8996 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C8999 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C9001 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C9093 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C9094 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C9095 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C9096 1-124-779-00 ELECT CHIP 10UF 20.00% 16V
C9097 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C9098 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C9099 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C9101 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C9102 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C9103 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C9104 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C9105 1-107-715-11 ELECT 22UF 20.00% 16V
C9106 1-126-947-11 ELECT 47UF 20.00% 25V
C9107 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C9108 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
< CONNECTOR >
CN8805 1-793-498-11 CONNECTOR, BOARD TO BOARD 50P
CN8806 1-815-672-11 CONNECTOR, RGB 21P
< DIODE >
D8800 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8801 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8802 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8803 8-719-108-12 DIODE RD9.1EW
D8805 8-719-158-49 DIODE RD12SB2
D8806 8-719-158-49 DIODE RD12SB2
D8807 8-719-158-49 DIODE RD12SB2
D8808 8-719-158-49 DIODE RD12SB2
D8809 8-719-158-49 DIODE RD12SB2
D8810 8-719-158-49 DIODE RD12SB2
D8811 8-719-158-49 DIODE RD12SB2
D8812 8-719-158-49 DIODE RD12SB2
D8813 8-719-158-49 DIODE RD12SB2
D8814 8-719-158-49 DIODE RD12SB2
D8815 8-719-158-49 DIODE RD12SB2
D8816 8-719-158-49 DIODE RD12SB2
D8817 8-719-158-49 DIODE RD12SB2
D8818 8-719-158-49 DIODE RD12SB2
D8819 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8820 8-719-158-49 DIODE RD12SB2
D8821 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8822 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8823 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8824 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8825 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8826 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8827 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8828 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8829 8-719-056-85 DIODE UDZ-TE-17-8.2B
D8830 8-719-158-49 DIODE RD12SB2
D8831 8-719-158-49 DIODE RD12SB2
D8832 8-719-158-49 DIODE RD12SB2
D8833 8-719-158-49 DIODE RD12SB2
D8839 8-719-108-12 DIODE RD9.1EW
< FERRITE BEAD >
FB8800 1-469-869-21 FERRITE 0UH
< FILTER >
FL8800 1-236-071-11 ENCAPSULATED COMPONENT
FL8801 1-236-071-11 ENCAPSULATED COMPONENT
FL8802 1-236-071-11 ENCAPSULATED COMPONENT
FL8803 1-236-071-11 ENCAPSULATED COMPONENT
FL8804 1-236-071-11 ENCAPSULATED COMPONENT
FL8805 1-233-765-21 FILTER
FL8806 1-233-768-21 FILTER
FL8807 1-233-766-21 FILTER
FL8808 1-236-071-11 ENCAPSULATED COMPONENT
FL8809 1-236-071-11 ENCAPSULATED COMPONENT
FL8811 1-236-071-11 ENCAPSULATED COMPONENT
< IC >
IC8101 8-759-576-76 IC TDA2822D013TR
IC8800 8-752-072-94 IC CXA1875AM-T4
IC8801 8-752-096-06 IC CXA2163Q-T6
IC8802 8-759-485-79 IC TC7SET08FU(TE85)
IC8803 8-752-386-17 IC CXD2064Q
IC8806 8-752-096-83 IC CXA2149AQ-TL
IC8809 8-759-439-64 IC HEF4053BT
IC8810 8-759-587-03 IC TDA8601T
< JACK >
J8800 1-770-989-11 JACK, PIN 2P
