Sony KD-32NS100B - Page 77

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 77 -
Q702 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q901 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q902 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q903 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q904 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
Q905 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
< RESISTOR >
R310 1-216-009-91 RES-CHIP 22 5% 1/10W
R334 1-216-295-91 SHORT 0
R339 1-216-295-91 SHORT 0
R350 1-216-295-91 SHORT 0
R361 1-216-827-11 RES-CHIP 3.3K 5% 1/16W
R362 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R363 1-216-037-00 RES-CHIP 330 5% 1/10W
R364 1-216-295-91 SHORT 0
R365 1-216-820-11 RES-CHIP 820 5% 1/16W
R366 1-216-821-11 RES-CHIP 1K 5% 1/16W
R367 1-216-855-11 RES-CHIP 680K 5% 1/16W
R368 1-216-855-11 RES-CHIP 680K 5% 1/16W
R369 1-216-295-91 SHORT 0
R371 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R372 1-216-009-91 RES-CHIP 22 5% 1/10W
R373 1-216-066-00 RES-CHIP 5.1K 5% 1/10W
R501 1-216-809-11 RES-CHIP 100 5% 1/16W
R502 1-216-809-11 RES-CHIP 100 5% 1/16W
R503 1-216-295-91 SHORT 0
R504 1-216-295-91 SHORT 0
R505 1-216-295-91 SHORT 0
R506 1-216-025-11 RES-CHIP 100 5% 1/10W
R507 1-216-025-11 RES-CHIP 100 5% 1/10W
R508 1-216-809-11 RES-CHIP 100 5% 1/16W
R509 1-216-809-11 RES-CHIP 100 5% 1/16W
R510 1-216-818-11 RES-CHIP 560 5% 1/16W
R511 1-216-818-11 RES-CHIP 560 5% 1/16W
R512 1-216-818-11 RES-CHIP 560 5% 1/16W
R513 1-216-818-11 RES-CHIP 560 5% 1/16W
R514 1-216-818-11 RES-CHIP 560 5% 1/16W
R515 1-216-818-11 RES-CHIP 560 5% 1/16W
R516 1-216-821-11 RES-CHIP 1K 5% 1/16W
R517 1-216-821-11 RES-CHIP 1K 5% 1/16W
R518 1-216-295-91 SHORT 0
R520 1-208-776-11 METAL CHIP 560 0.5% 1/10W
R521 1-216-295-91 SHORT 0
R523 1-208-776-11 METAL CHIP 560 0.5% 1/10W
R524 1-216-295-91 SHORT 0
R526 1-208-776-11 METAL CHIP 560 0.5% 1/10W
R528 1-216-037-00 RES-CHIP 330 5% 1/10W
R529 1-218-865-91 METAL CHIP 5.6K 0.5% 1/10W
F4 A
IC506 8-759-640-16 IC TC7SET04F(TE85R)
IC601 8-752-409-78 IC CXD2095AQ
IC602 8-759-641-60 IC MT47LC1M16A1TG-7S
IC603 8-759-669-75 IC TLC2932IPWR
IC710 6-700-797-01 IC CXD9666Q
IC801 8-759-672-57 IC CXD9509AQ
IC802 8-759-677-37 IC MT48LC2M32B2TG-6
< COIL >
L304 1-412-029-11 INDUCTOR 10UH
L305 1-412-029-11 INDUCTOR 10UH
L501 1-412-026-11 INDUCTOR 1UH
L502 1-412-026-11 INDUCTOR 1UH
L503 1-412-026-11 INDUCTOR 1UH
L504 1-412-026-11 INDUCTOR 1UH
L505 1-412-029-11 INDUCTOR 10UH
L506 1-412-026-11 INDUCTOR 1UH
L508 1-412-029-11 INDUCTOR 10UH
L509 1-412-029-11 INDUCTOR 10UH
L511 1-412-026-11 INDUCTOR 1UH
L512 1-412-026-11 INDUCTOR 1UH
L604 1-412-029-11 INDUCTOR 10UH
L605 1-412-029-11 INDUCTOR 10UH
L700 1-412-029-11 INDUCTOR 10UH
L701 1-412-029-11 INDUCTOR 10UH
< TRANSISTOR >
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q501 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q502 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q503 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q510 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q511 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q512 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q513 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q514 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q515 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q516 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q517 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q518 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q519 1-801-806-11 TRANSISTOR DTC144EKA
Q521 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q522 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q523 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q524 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q602 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q700 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q701 8-729-026-49 TRANSISTOR 2SA1037AK-T146
B4
