Sony KD-32NS100B - Page 93

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 93 -
G1
C4606 1-162-318-11 CERAMIC 0.001UF 10.00% 500V
C4607 1-165-602-91 CERAMIC 220PF 10 2KV
C4608 1-126-967-11 ELECT 47UF 20.00% 50V
C4609 1-130-777-00 MYLAR 0.1UF 5.00% 100V
C4610 1-130-777-00 MYLAR 0.1UF 5.00% 100V
C4611 1-126-971-11 ELECT 470UF 20.00% 50V
C4612 1-136-165-00 FILM 0.1UF 5.00% 50V
C4615 1-136-165-00 FILM 0.1UF 5.00% 50V
C4616 1-104-665-11 ELECT 100UF 20.00% 25V
C4618 1-136-165-00 FILM 0.1UF 5.00% 50V
C4619 1-104-665-11 ELECT 100UF 20.00% 25V
C4621 1-136-165-00 FILM 0.1UF 5.00% 50V
C4622 1-104-665-11 ELECT 100UF 20.00% 25V
C4623 1-136-165-00 FILM 0.1UF 5.00% 50V
C4624 1-126-961-11 ELECT 2.2UF 20.00% 50V
C4625 1-115-766-51 ELECT 0.0022F 20.00% 16V
C4626 1-104-665-11 ELECT 100UF 20.00% 25V
C4627 1-136-165-00 FILM 0.1UF 5.00% 50V
C4628 1-115-766-51 ELECT 0.0022F 20.00% 16V
C4629 1-115-792-11 ELECT 0.0022F 20.00% 25V
< CONNECTOR >
CN4600 £ 1-580-843-11 PIN, CONNECTOR (POWER)
CN4601 *1-564-506-11 PLUG, CONNECTOR 3P
CN4602 *1-764-333-11 PLUG, CONNECTOR 10P
CN4603 1-564-511-11 PLUG, CONNECTOR 8P
< DIODE >
D4600 £ 8-719-025-88 DIODE GBU4JL-6088
D4601 8-719-080-26 DIODE SARS01V0
D4602 8-719-075-11 DIODE AG01ZV0
D4603 8-719-075-11 DIODE AG01ZV0
D4604 8-719-075-11 DIODE AG01ZV0
D4605 8-719-075-11 DIODE AG01ZV0
D4606 8-719-072-17 DIODE BYW100-200RL
D4607 6-500-081-01 DIODE RK34-LF-C4
D4608 8-719-312-10 DIODE RU4AM-T3
D4609 6-500-082-01 DIODE RJ43-LF-T2
D4611 8-719-991-33 DIODE 1SS133T-77
D4612 8-719-063-70 DIODE D1NL20U-TA2
< FERRITE BEAD >
FB4601 1-535-465-11 LEAD, JUMPER (5.0MM)
FB4602 1-410-396-41 FERRITE 0.45UH
FB4603 1-410-396-41 FERRITE 0.45UH
FB4604 1-410-396-41 FERRITE 0.45UH
FB4605 1-410-396-41 FERRITE 0.45UH
FB4606 1-535-465-11 LEAD, JUMPER (5.0MM)
< IC >
IC4600 £ 6-700-292-01 IC STR-L474-LF428
IC4601 £ 8-749-013-21 IC TLP721(D4-G)
IC4602 6-700-293-01 IC SE-012N-LF4
IC4604 8-759-648-19 IC L7809CV/LSY
< COIL >
L4600 1-410-397-21 FERRITE 1.1UH
L4601 1-535-465-11 LEAD, JUMPER (5.0MM)
L4602 1-412-519-11 INDUCTOR 3.3UH
L4603 1-412-519-11 INDUCTOR 3.3UH
L4604 1-412-519-11 INDUCTOR 3.3UH
< IC LINK >
PS4601 1-535-465-11 LEAD, JUMPER (5.0MM)
PS4602 1-535-465-11 LEAD, JUMPER (5.0MM)
PS4603 £ 1-801-550-21 PROTECTOR, MODULE
PS4604 £ 1-801-550-21 PROTECTOR, MODULE
PS4605 £ 1-801-549-21 PROTECTOR, MODULE
< TRANSISTOR >
Q4600 8-729-029-56 TRANSISTOR DTA144ESA
Q4601 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R4600 £ 1-217-155-00 METAL 1 10% 2W
R4601 £ 1-260-127-11 CARBON 220K 5% 1/2W
R4602 £ 1-217-418-00 FUSIBLE 0.47 10% 1/2W
R4603 1-260-133-11 CARBON 680K 5% 1/2W
R4604 1-215-884-11 METAL OXIDE 47 5% 2W
R4605 1-249-401-11 CARBON 47 5% 1/4W
R4607 1-249-421-11 CARBON 2.2K 5% 1/4W
R4608 £ 1-260-128-91 CARBON 270K 5% 1/2W
R4609 1-249-419-11 CARBON 1.5K 5% 1/4W
R4610 1-249-403-11 CARBON 68 5% 1/4W
R4611 1-249-418-11 CARBON 1.2K 5% 1/4W
R4612 1-249-419-11 CARBON 1.5K 5% 1/4W
R4613 1-259-880-11 CARBON 2.2M 5% 1/4W
R4614 1-249-417-11 CARBON 1K 5% 1/4W
R4615 1-249-425-11 CARBON 4.7K 5% 1/4W
R4616 1-216-366-00 METAL OXIDE 0.56 5% 2W
R4617 1-249-415-11 CARBON 680 5% 1/4W
< RELAY >
RY4601 £ 1-755-389-11 RELAY (AC POWER)
< TRANSFORMER >
T4601 £ 1-437-445-11 TRANSFORMER, CONVERTER (SRT)
