Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R883 1-249-403-11 CARBON 68 5% 1/4W
< VIBRATOR >
X801 1-767-697-11 VIBRATOR, CRYSTAL (32kHz)
X802 1-781-598-11 VIBRATOR, CERAMIC (8MHz)
*************************************************************
* 1-677-031-11 FRONT BOARD
************
< CAPACITOR >
C871 1-162-282-31 CERAMIC 100PF 10% 50V
C872 1-127-888-21 CERAMIC 0.1uF 10% 50V
< IC >
IC804 8-749-016-97 IC NJL62H400A
< CABLE HOLDER >
* KH805 1-565-386-11 HOLDER, CABLE 5P
< RESISTOR >
R401 1-249-413-11 CARBON 470 5% 1/4W
R402 1-249-412-11 CARBON 390 5% 1/4W
R403 1-249-413-11 CARBON 470 5% 1/4W
R404 1-249-413-11 CARBON 470 5% 1/4W
R405 1-249-415-11 CARBON 680 5% 1/4W
R406 1-249-415-11 CARBON 680 5% 1/4W
R407 1-249-417-11 CARBON 1K 5% 1/4W
R408 1-249-418-11 CARBON 1.2K 5% 1/4W
R409 1-249-419-11 CARBON 1.5K 5% 1/4W
R410 1-249-421-11 CARBON 2.2K 5% 1/4W
R411 1-247-843-11 CARBON 3.3K 5% 1/4W
R412 1-249-416-11 CARBON 820 5% 1/4W
R413 1-247-843-11 CARBON 3.3K 5% 1/4W
R414 1-249-418-11 CARBON 1.2K 5% 1/4W
R415 1-249-419-11 CARBON 1.5K 5% 1/4W
R416 1-249-421-11 CARBON 2.2K 5% 1/4W
< SWITCH >
S818 1-762-798-11 SWITCH, KEY BOARD (VOLUME +)
S819 1-762-798-11 SWITCH, KEY BOARD (VOLUME –)
S820 1-762-798-11 SWITCH, KEY BOARD (SOUND)
S821 1-762-798-11 SWITCH, KEY BOARD (MEGA BASS)
S822 1-762-798-11 SWITCH, KEY BOARD (OPERATE)
S823 1-762-798-11 SWITCH, KEY BOARD (STANDBY)
S824 1-762-798-11 SWITCH, KEY BOARD (SLEEP)
S825 1-762-798-11 SWITCH, KEY BOARD (CLOCK)
S826 1-762-798-11 SWITCH, KEY BOARD (TIMER)
S827 1-762-798-11 SWITCH, KEY BOARD (CD OPEN/CLOSE Z)
S828 1-762-798-11 SWITCH, KEY BOARD (DISPLAY)
S829 1-762-798-11 SWITCH, KEY BOARD (MODE MONO/ST ISS)
S830 1-762-798-11 SWITCH, KEY BOARD (ENTER MEMORY)
S831 1-762-798-11 SWITCH, KEY BOARD (COUNTER RESET)
S832 1-762-798-11 SWITCH, KEY BOARD (DIR MODE)
S833 1-762-798-11 SWITCH, KEY BOARD (SUMMER TIME)
*************************************************************
* 1-673-339-11 HEAD RELAY BOARD
*****************
*************************************************************
* 1-677-029-11 H/P BOARD
**********
< CAPACITOR >
C141 1-162-294-31 CERAMIC 0.001uF 10% 50V
C241 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CNP313 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< JACK >
J301 1-566-891-11 JACK (i)
< COIL >
L101 1-410-509-11 INDUCTOR 10uH
L201 1-410-509-11 INDUCTOR 10uH
L301 1-410-750-41 INDUCTOR 0.47uH
< RESISTOR >
R132 1-249-429-11 CARBON 10K 5% 1/4W
R232 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
* 1-677-028-11 LINE BOARD
***********
< CAPACITOR >
C341 1-126-963-11 ELECT 4.7uF 20% 50V
C342 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CNP312 1-695-105-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D331 8-719-991-33 DIODE 1SS133T-77
D332 8-719-991-33 DIODE 1SS133T-77
< IC >
IC704 8-749-921-12 IC GP1F32T (OPTICAL DIGITAL OUT (CD))
< JACK >
J311 1-566-822-21 JACK (LINE OUT)
J312 1-566-822-21 JACK (LINE IN)
FRONTCONTROL H/P LINEHEAD RELAY
